Full specifications (PDF)
Projection Method:
- Front
- Ceiling
3D Type:
3D Ready
Platform Supported:
- PC
- Mac
ViewSonic PJD5523w Products Model Overview
The ViewSonic PJD5523w is an advanced DLP projector which includes BrilliantColor technology to produce more vibrant colors, with high brightness and contrast ratio make it shine in virtually any lighting situation. The PJD5523w delivers 2,700 ANSI lumens, 3,000:1 dynamic contrast ratio with a widescreen 1280x800 WXGA native resolution. This projector is packed with features like HDMI port, 120Hz / 3D-ready for any PC-based 3D applications, integrated speaker for multimedia and supports HD 1080p video. Filter-less design and energy saving Eco-mode provide for zero maintenance and longer product life. With an all new design of only 3.2 inches in height and lightweight at 5.7 lbs, it's perfect for use in corporate, education and home theater environments.
ViewSonic PJD5523W Products Overview
The ViewSonic PJD5523w is an advanced DLP projector which includes BrilliantColor technology to produce more vibrant colors, with high brightness and contrast ratio make it shine in virtually any lighting situation. The PJD5523w delivers 2,700 ANSI lumens, 3,000:1 dynamic contrast ratio with a widescreen 1280x800 WXGA native resolution. This projector is packed with features like HDMI port, 120Hz / 3D-ready for any PC-based 3D applications, integrated speaker for multimedia and supports HD 1080p video. Filter-less design and energy saving Eco-mode provide for zero maintenance and longer product life. With an all new design of only 3.2 inches in height and lightweight at 5.7 lbs, it's perfect for use in corporate, education and home theater environments.
Technical Information
Projection Lens
Maximum Diagonal Image Size:
25 ft
Optical Zoom:
1.2x
Minimum Projection Distance:
55.12"
Maximum Projection Distance:
26.25 ft
Lamp
Number of Lamps:
1
Lamp Power:
180 W
Normal Mode Lamp Life:
5000 Hour
Economy Mode Lamp Life:
6000 Hour
Standard Mode Brightness:
2700 lm
Color Supported:
16.7 Million Colors (24-bit)
Native Resolution:
1280 x 800
Graphic Mode:
WXGA
Maximum Resolution:
1600 x 1200
Native Aspect Ratio:
16:10
Compatible Aspect Ratio:
- 4:3
- 16:9
Throw Ratio:
1.47 to 1.83:1
Contrast Ratio:
2,000:1
Vertical Keystone Correction:
-40°/+40°
Video
Video Signal Format:
- NTSC
- PAL
- SECAM
Video Signal Standard:
HDTV
Input Scan Format:
1080i
Output Scan Format:
720p
Audio
Number of Speakers:
1
Speaker Output Power:
1 W
Speaker Output Mode:
Mono
Interfaces/Ports
HDMI:
Yes
Composite Video:
Yes
Component Video:
Yes
VGA In:
Yes
Power Description
Input Voltage:
- 110 V AC
- 220 V AC
Operating Power Consumption:
235 W
Physical Characteristics
Color:
Black
Form Factor:
Ceiling Mountable
Height:
3.2"
Width:
11.2"
Depth:
9.2"
Weight (Approximate):
5.73 lb
Miscellaneous
Package Contents:
- Portable WXGA DLP Projector
- Power Cable
- VGA Cable
- Remote Control with Batteries
- Quick Start Guide
- CD-ROM (User Guide)
Certifications & Standards:
- CB
- CCC
- PSB
- C-tick
- KC
- SASO
- CE
- GOST-R
- Ukr
- ErP
- SVHC list
- UL
- FCC
- cUL/CSA
- Argen
- NOM
Environmentally Friendly:
Yes
Environmental Certification:
RoHS
Warranty
Limited Warranty:
3 Year
Parts Warranty/Labor:
1 Year - Lamp
Item Numbers
GTIN:
0675650067040, 0675650180688, 0766907526714
UPC:
675650067040, 675650180688, 766907526714
EAN:
0675650067040, 0675650180688, 0766907526714
UNSPSC:
45111609
Get help from a Barcoding Expert!
The ViewSonic PJD5523W Products is also known as
PJD5523W
