Unitech PA520 – Mobile Computer

Part Number: PA520-9S60UMDG
Model: PA520
Add to My Shopping List Add to Compare
Discontinued See Replacement

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Connectivity Technology
Wireless
Light Source
Laser
Barcode Symbology Supported
1D:UPC-A/EEAN-8/13CodabarCode 39Code 39 full ASCICode 93Code 32Interleaved & Std. 2 of 5EAN 128Code 11DeltaMSI/PlesseyCode 128ToshibaRSS expendedRSS LimitedRSS14
Drop Specification
39.37"

Product Description:

  Unitech Rugged Enterprise PDA - Texas Instruments Cortex A8 800 MHz - 512 MB RAM - 512 MB Flash - 3.5" VGA, QVGA LCD - 22 Keys - Numeric Keyboard - Wireless LAN - Bluetooth
Explore all Unitech PA520 Mobile Computers
Add to Quote
Unitech PA520-9S60UMDG Mobile Computer
Unitech PA520-9S60UMDG Mobile Computer
Unitech PA520-9S60UMDG Mobile Computer
Unitech PA520-9S60UMDG Mobile Computer Unitech PA520-9S60UMDG Mobile Computer Unitech PA520-9S60UMDG Mobile Computer
Full specifications (PDF)

Unitech PA520 Mobile Computer Model Overview

The Unitech PA520 Rugged Enterprise PDA (Windows) is compact, tough, and brings a 1D/2D scanner, NFC, and Windows Embedded Handheld 6.5 OS to the table. The PA520 is built to enhance the workspace for anyone in sales automation and field service. The PA520 hosts a powerful scanner allowing it to scan barcodes and RFID tags even when they are printed on poorly or worn down. Bring comfort and convenience to your workforce with eh Unitech PA520.
Unitech PA520-9S60UMDG Mobile Computer Overview
Unitech PA520 is a compact sized enterprise PDA that provides a comprehensive wireless platform since it integrated WiFi and Bluetooth communication, making it quick and easy to stay connected. Equipped with 1D / 2D imager, RFID reader, NFC and Windows embedded handheld 6.5 operating system all in a compact and durable form factor, this device is designed to empower the mobile workforce for daily jobs in sales automation and field service applications.
Full specifications (PDF)
Technical Information
Connectivity Technology:
Wireless
Light Source:
Laser
Barcode Symbology Supported:
1D:
  • UPC-A/E
  • EAN-8/13
  • Codabar
  • Code 39
  • Code 39 full ASCI
  • Code 93
  • Code 32
  • Interleaved & Std. 2 of 5
  • EAN 128
  • Code 11
  • Delta
  • MSI/Plessey
  • Code 128
  • Toshiba
  • RSS expended
  • RSS Limited
  • RSS14
Drop Specification:
39.37"
Processor & Chipset
Processor Manufacturer:
Texas Instruments
Processor Type:
Cortex A8
Processor Speed:
800 MHz
Memory
Standard Memory:
512 MB
Flash Memory:
512 MB
Memory Card Slot:
Yes
Memory Card Supported:
microSD
Maximum Memory Card Size Supported:
32 GB
Display & Graphics
Screen Size:
3.5"
Screen Mode:
  • VGA
  • QVGA
Screen Resolution:
480 x 640
Display Screen Type:
LCD
Touchscreen Information
Touchscreen:
Yes
Touchscreen Type:
Capacitive
Keyboard/Keypad
Number of Keys:
22
Keyboard Type:
Numeric
Network & Communication
Wireless LAN:
Yes
Wireless LAN Standard:
IEEE 802.11a/b/g/n
Bluetooth:
Yes
Interfaces/Ports
USB:
Yes
Software
Operating System:
Microsoft Windows Embedded Handheld 6.5 Classic
Battery Information
Battery Capacity:
2400 mAh
Battery Included:
Yes
Physical Characteristics
Height:
5"
Width:
3"
Depth:
1"
Weight (Approximate):
7.76 oz
Miscellaneous
Package Contents:
  • Rugged Enterprise PDA
  • Battery
Certifications & Standards:
  • CCX Version 4 Certification
  • IP42
  • CE
  • NCC
  • FCC
  • BSMI
  • VCCI
  • CCC
Environmentally Friendly:
Yes
Environmental Certification:
RoHS
Warranty
Limited Warranty:
1 Year
Item Numbers
UNSPSC: 43211715
