Unitech MS320 – Barcode Scanner – 1D

Part Number: MS320-CUCB0S-SG
Model: MS320

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

Form Factor
Handheld
Scanner Capability
1D
Scanner Type
CCD, Imager

Product Description:

  Unitech Handheld Imager Scanner (1D) - Cable Connectivity - 300 scan/s - 12" Scan Distance - 1D - Imager - Black

Unitech MS320 Barcode Scanner Model Overview

The MS320 is a scanner that matches a laser scanner in performance by incorporating aggressive long range CCD scanning technology. Besides supporting most common one dimensional barcodes the MS320 also supports a two dimensional barcode, PDF417. This barcode is selected for applications in areas such as the automotive industry for key applications as shipping, product evidence, quality conveyance, production broadcast, configuration management and material safety data sheets. Both contact and wide reading enables the worker to read labels up to 25 cm.
Unitech MS320-CUCB0S-SG Barcode Scanner Overview
The MS320 imager scanner matches laser scanning performance by incorporating aggressive long range CCD scanning technology. It also provides excellent user-comfort thanks to its ergonomic and lightweight design. It is also rugged enough to withstand multiple 5-foot drops to concrete.

In addition to reading most common one dimensional barcodes, the MS320 also reads PDF417. This barcode is selected for applications in areas such as the automotive industry for key applications as shipping, product evidence, quality conveyance, production broadcast, configuration management and material safety data sheets.
Technical Information
Connectivity Technology:
Cable
Scanning Capability:
1D
Barcode Symbology Supported:
  • Code 39
  • Code 39 Full ASCII
  • Codabar
  • Pharmacy Code(Italian)
  • Standard 2 of 5
  • Industrial 2 of 5
  • Interleave 2 of 5
  • Matrix 2 of 5
  • Code 93
  • Code 128/UCC EAN 128
  • MSI
  • Plessey
  • UPC/EAN codes incl.add-ons
  • ISBN
  • Telepen
  • RSS Code
Image Sensor Type:
Imager
Scan Rate:
300 scan/s
Maximum Scan Resolution:
4 mil
Depth of Field:
  • 0mm - 250mm@20mil - Code 39
Scanning Distance:
12"
Cable Type Included:
USB
Stand Included:
Yes
Interfaces/Ports
Host Interface:
USB
Power Description
Input Voltage:
5 V DC
Physical Characteristics
Color:
Black
Height:
7.4"
Width:
3.1"
Depth:
4"
Weight (Approximate):
6.60 oz
Miscellaneous
Package Contents:
  • Handheld Imager Scanner (1D)
  • USB Cable
  • Hands-Free Stand
Additional Information:

USB Cable separate

Platform Supported:
PC
Certifications & Standards:
  • UL
  • FCC CLASS A
  • CE CLASS A
  • BSMI
Warranty
Limited Warranty:
5 Year
Item Numbers
UNSPSC: 43211701
