The Unitech MS250 Handheld Scanner is the perfect blend of reliability and performance, designed to enhance productivity in various applications, including point-of-sale, inventory control, and personal data identification. With advanced scanning capabilities, it swiftly captures data, even from damaged or poorly printed barcodes, achieving up to 200 scans per second. This user-friendly device connects effortlessly via USB, eliminating the need for additional installations. Its compact design ensures comfort during extended use, and the built-in loud beeper provides clear decoding feedback, making it ideal for busy environments.
Key Features
Aggressive scan rate: up to 200 scans/sec
Lightweight and ergonomic design
Reads most 1D barcode types: including GS1 dataBar symbology
Multi-interface Communication: USB, Keyboard Wedge, RS232, and USB emulation COM port driver
Supports minimum resolution: 3mil/0.076mm
Available in dual colors: dark blue and beige
Specifications
Electrical:
Operation Voltage: 5VDC
Current Consumption: Operation mode <120mA; Standby mode <20mA
Optical & Performance:
Receiving Device: Linear CCD Sensor
Light Source: Visible Red light 635nm LED
Max. Resolution: 3mil (0.076mm) @ PCS90%
Scan Rate: 200 scans/second +10%
Scanning Angle: Forward & Backward ±10°-30° (±5°), Left & Right ±60° (±5°)
Mechanical:
Housing Material: ABS
Scanner Dimension: 163.3mm x 79mm x 62.5mm
Scanner Weight: 83g
Environmental:
Operating Temperature: 0°C to 50°C (32°F to 122°F)
Storage Temperature: -20°C to 70°C (-4°F to 158°F)
Relative Humidity: 20% to 95% (Non-condensing)
ESD Protection: Functional after 8K Contact and 12K Air
Unitech MS250-CUCB00-DG Barcode Scanner Overview
Introducing the MS250.
Our MS250 contact barcode scanner features a versatile design to meet even more of your data collection needs. The MS250 offers more powerful and flexible performance than your standard entry-level scanner.
What barcode symbologies does the Unitech MS250 scanner support?
The MS250 supports a comprehensive range of 1D linear barcode symbologies including UPC/EAN/JAN, Code 39, Codabar, ITF 2/5, Code 128, Code 11, Code 93, and MSI. This broad symbology support makes it suitable for diverse retail, warehouse, and document processing applications where you need to read multiple barcode formats reliably.
Is the Unitech MS250 compatible with my computer system?
Yes, the MS250 offers flexible connectivity with both USB and PS/2 interfaces, making it compatible with PC, Macintosh, and IBM Terminal systems. The scanner connects directly to your existing computer infrastructure without requiring specialized adapters, and we offer it ready to integrate into your scanning workflow.
Can the MS250 read damaged or poorly printed barcodes?
Yes, the MS250 is specifically designed to deliver superior data capture performance even when barcodes are damaged or poorly printed. This capability makes it an excellent choice for high-volume environments like inventory control and point-of-sale operations where barcode quality can be inconsistent.
What are the operating temperature and environmental specifications for the MS250?
The MS250 operates reliably in temperatures from 0°C to 50°C (32°F to 122°F) with operating humidity between 10% and 85% non-condensing. It can withstand ambient light up to 36,000 Lux and includes ESD protection, making it suitable for typical warehouse and retail environments.
How durable is the Unitech MS250 for warehouse use?
The MS250 is built with a rubber and ABS plastic case and is designed to survive a 1.5-meter drop onto concrete, providing the durability needed for active warehouse and logistics operations. At 130 grams without cable, it's also lightweight enough for all-day handheld scanning tasks.
What makes the MS250 a cost-effective scanning solution?
The MS250 combines reliable CCD linear imaging technology with broad symbology support and multi-platform compatibility at a competitive price point, making it an ideal general-purpose scanner for point-of-sale, document processing, personal data identification, and inventory control. We offer the MS250 with the performance and features you need without premium pricing, helping you maximize your scanning ROI across multiple applications.
The Unitech MS250-CUCB00-DG Barcode Scanner is also known as
UNI-MS250CUCB00DG
or MS250CUCB00DG.
Full specifications (PDF)
