The Unitech MS250 Handheld Scanner is the perfect blend of reliability and performance, designed to enhance productivity in various applications, including point-of-sale, inventory control, and personal data identification. With advanced scanning capabilities, it swiftly captures data, even from damaged or poorly printed barcodes, achieving up to 200 scans per second. This user-friendly device connects effortlessly via USB, eliminating the need for additional installations. Its compact design ensures comfort during extended use, and the built-in loud beeper provides clear decoding feedback, making it ideal for busy environments.
Key Features
Aggressive scan rate: up to 200 scans/sec
Lightweight and ergonomic design
Reads most 1D barcode types: including GS1 dataBar symbology
Multi-interface Communication: USB, Keyboard Wedge, RS232, and USB emulation COM port driver
Supports minimum resolution: 3mil/0.076mm
Available in dual colors: dark blue and beige
Specifications
Electrical:
Operation Voltage: 5VDC
Current Consumption: Operation mode <120mA; Standby mode <20mA
Optical & Performance:
Receiving Device: Linear CCD Sensor
Light Source: Visible Red light 635nm LED
Max. Resolution: 3mil (0.076mm) @ PCS90%
Scan Rate: 200 scans/second +10%
Scanning Angle: Forward & Backward ±10°-30° (±5°), Left & Right ±60° (±5°)
Mechanical:
Housing Material: ABS
Scanner Dimension: 163.3mm x 79mm x 62.5mm
Scanner Weight: 83g
Environmental:
Operating Temperature: 0°C to 50°C (32°F to 122°F)
Storage Temperature: -20°C to 70°C (-4°F to 158°F)
Relative Humidity: 20% to 95% (Non-condensing)
ESD Protection: Functional after 8K Contact and 12K Air
Unitech MS250-C0C000-DG Barcode Scanner Overview
Introducing the MS250.
Our MS250 contact barcode scanner features a versatile design to meet even more of your data collection needs. The MS250 offers more powerful and flexible performance than your standard entry-level scanner.
What type of barcode scanner is the Unitech MS250-C0C000-DG?
The Unitech MS250-C0C000-DG is a 1D linear imager CCD barcode scanner designed for general-purpose applications. It's a corded handheld scanner that delivers reliable data capture with excellent performance, even when barcodes are damaged or poorly printed, making it ideal for point-of-sale, document processing, and inventory control environments.
What cable do I need to connect the MS250-C0C000-DG scanner?
The MS250-C0C000-DG is sold as a scanner-only unit without a cable included. To connect this scanner, you'll need to purchase a USB cable separately—we offer Part# 1550-900076G for this purpose. Contact us today to order the compatible cable for your setup.
What barcode symbologies does the Unitech MS250 support?
The MS250 supports a comprehensive range of 1D barcode symbologies including UPC-A/UPC-E, EAN-8/EAN-13, Code 39, Code 128, Codabar, Interleaved 2 of 5, Industrial 2 of 5, Code 93, Code 11, MSI Plessy Code, and China Postal Code. This broad symbology support makes it suitable for diverse retail and warehouse applications.
What is the scan rate and reading distance of the MS250-C0C000-DG?
The MS250 features a scan rate of 230 scans per second with a 2048 pixel CCD sensor. For reading distance, it can read 4 mil Code39 barcodes at 80–90 mm, 5 mil Code39 at 70–120 mm, and 15.6 mil EAN barcodes at 30–360 mm, providing flexibility across different barcode sizes and distances.
Can the MS250 handle harsh warehouse environments?
Yes, the MS250 is designed for demanding environments with an operating temperature range of 0°C to 50°C (32°F to 122°F), operating humidity of 10% to 85% non-condensing, and ambient light immunity up to 5000 Lux under fluorescent lighting. The scanner features a durable rubber and ABS plastic construction and can withstand 1.5-meter drops onto concrete, making it suitable for warehouse and logistics operations.
What are the physical dimensions and weight of the MS250 scanner?
The Unitech MS250-C0C000-DG measures 93mm (L) x 61mm (W) x 182mm (H) and weighs 130 grams without the cable. Its compact handheld form factor makes it easy to grip and use throughout the day in retail, inventory, and document processing applications.
The Unitech MS250-C0C000-DG Barcode Scanner is also known as
MS250C0C000DG
Full specifications (PDF)
