MS146I-4G Barcode Card Reader

Part Number: MS146I-4G
Model: MS146
Add to My Shopping List Add to Compare
Discontinued See Replacement

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Connectivity Technology
Cable
Barcode Symbology Supported
China Postal CodeCodabarCode 11Code 32Code 39 (Standard)Code 39 Full ASCIICode 93Code 128Delta CodeEAN-8 with Add-on CodeEAN-13 with Add-on CodeEAN-128Interleaved 2 of 5ISBN / Bookland EANISBT 128Italian PharmacyLabel Code IVLabel Code VMSI/PLESSEYStandard 2 of 5Toshiba CodeUPC-A with Add-on CodeUPC-E with Add-on Code
Light Source
LED
Maximum Scan Resolution
6 mil

Product Description:

  Unitech MS146 Bar Code Slot Reader - Wired - Photo Diode
Explore all Unitech MS146 Barcode Card Readers
Add to Quote
MS146I-4G Barcode Card Reader
MS146I-4G Barcode Card Reader
MS146I-4G Barcode Card Reader
MS146I-4G Barcode Card Reader MS146I-4G Barcode Card Reader

Full specifications (PDF)

Unitech MS146 Barcode Card Reader Model Overview

The Unitech MS146 barcode slot reader is a flexible, cost effective solution when reliability is essential. With a resolution of up to 6 mils (0.15 mm), the MS146 is capable of reading any barcoded identification badge. The MS146's sealed optical system is available in both visible light or infrared. The infrared units ensure accurate reading of either visible and laminated badges. The convenient USB interface, water resistant base, rugged housing, and IP54 rated sealing make the MS146 a popular choice in any environment.
MS146I-4G Barcode Card Reader Overview

The MS146 bar code slot readers is a flexible, cost effective solution when for a reliable and rugged slot reader. With a resolution of up to 6 mils (0.15 mm), the MS146 is capable of reading any bar coded identification badge. Its sealed optical system is available in both visible light or infrared. The infrared units ensure accurate reading of either visible and laminated badges. Its water resistant base, rugged housing, and IP54 rated sealing make the MS146 a popular choice in any environment. An optional mounting bracket is available to safely secure the unit in any direction. Decoded versions are easy to use and configure.

Full specifications (PDF)
Technical Information
Connectivity Technology:
Cable
Barcode Symbology Supported:
  • China Postal Code
  • Codabar
  • Code 11
  • Code 32
  • Code 39 (Standard)
  • Code 39 Full ASCII
  • Code 93
  • Code 128
  • Delta Code
  • EAN-8 with Add-on Code
  • EAN-13 with Add-on Code
  • EAN-128
  • Interleaved 2 of 5
  • ISBN / Bookland EAN
  • ISBT 128
  • Italian Pharmacy
  • Label Code IV
  • Label Code V
  • MSI/PLESSEY
  • Standard 2 of 5
  • Toshiba Code
  • UPC-A with Add-on Code
  • UPC-E with Add-on Code
Light Source:
LED
Maximum Scan Resolution:
6 mil
Depth of Field:
  • 0mm - 2mm
Interfaces/Ports
Host Interface:
USB
Power Description
Input Voltage:
5 V DC
Physical Characteristics
Form Factor:
Swipe
Height:
1.9"
Width:
1.4"
Depth:
3.8"
Weight (Approximate):
6.70 oz
Miscellaneous
Additional Information:

6 ft USB Cable

USB Cable separate

Certifications & Standards:
  • RoHS
Environmentally Friendly:
Yes
Environmental Certification:
RoHS
Warranty
Limited Warranty:
2 Year
Item Numbers
GTIN: 0778889870914
UPC: 778889870914
EAN: 0778889870914
UNSPSC: 43211701
