Unitech HT680 – Mobile Computer

Part Number: HT680-9560UADG
Model: HT680
Discontinued See Replacement
Item on backorder — chat for lead time

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Connectivity Technology
Wireless
Light Source
Laser
Barcode Symbology Supported
UPC-A/EEAN-8/13CodabarCode 39Code 39 full ASCICode 93Code 32Interleaved & Std. 2 of 5EAN 128Code 11DeltaMSI/PlesseyCode 128Toshiba
Drop Specification
72" To Concrete

Product Description:

  Unitech HT680 Handheld Terminal - Intel XScale PXA270 520 MHz - 128 MB RAM - 512 MB Flash - 2.7" LCD - 22 Keys - Numeric Keyboard - Wireless LAN - Bluetooth

Unitech HT680 Mobile Computer Model Overview

The Unitech HT680 is a compact and aggressive rugged mobile computer ideally suited for manufacturing, retail, logistics and transportation. Designed for the toughest work environments, the HT680 gives you the reliability and flexibility needed to increase productivity and efficiency in all of your data collection applications. The HT680 is built to last, protecting your investment and minimizing downtime. Compact and rugged, the HT680 is IP54 rated, safeguarding it from moisture and dust and can withstand 6-foot drops to concrete, the highest drop threshold in Unitech's line of mobile computers.
Unitech HT680-9560UADG Mobile Computer Overview

The HT680 is a compact and aggressive rugged mobile computer ideally suited for manufacturing, retail, logistics and transportation. Designed for the toughest work environments, the HT680 gives you the reliability and flexibility needed to increase productivity and efficiency in all of your data collection applications.

Technical Information
Connectivity Technology:
Wireless
Light Source:
Laser
Barcode Symbology Supported:
  • UPC-A/E
  • EAN-8/13
  • Codabar
  • Code 39
  • Code 39 full ASCI
  • Code 93
  • Code 32
  • Interleaved & Std. 2 of 5
  • EAN 128
  • Code 11
  • Delta
  • MSI/Plessey
  • Code 128
  • Toshiba
Drop Specification:
72" To Concrete
Processor & Chipset
Processor Manufacturer:
Intel
Processor Type:
XScale PXA270
Processor Speed:
520 MHz
Memory
Standard Memory:
128 MB
Flash Memory:
512 MB
Memory Card Slot:
Yes
Memory Card Supported:
SDHC
Display & Graphics
Screen Size:
2.7"
Screen Mode:
QVGA
Display Color:
Color
Display Screen Type:
LCD
Touchscreen Information
Touchscreen:
Yes
Keyboard/Keypad
Number of Keys:
22
Keyboard Type:
Numeric
Network & Communication
Wireless LAN:
Yes
Wireless LAN Standard:
IEEE 802.11b/g
Bluetooth:
Yes
Software
Operating System:
Windows CE 5.0
Battery Information
Battery Capacity:
2200 mAh
Battery Chemistry:
Lithium Ion (Li-Ion)
Battery Included:
Yes
Physical Characteristics
Height:
6.7"
Width:
2.1"
Depth:
1.2"
Weight (Approximate):
11.20 oz
Miscellaneous
Package Contents:
  • HT680 Handheld Terminal
  • Stylus
  • Battery
  • USB Cable
  • AC Adapter
  • User's Manual
  • Accessible Software
Certifications & Standards:
  • CE
  • IP54
  • FCC
  • CCC
  • VCCI
  • BSMI
Environmentally Friendly:
Yes
Environmental Certification:
RoHS
Item Numbers
GTIN: 5711045720024
EAN: 5711045720024
UNSPSC: 43211715
