Unitech HT630-VB0A1G Mobile Computer

Unitech HT630-A000BADG Mobile Computer A newer version of this item is available.
It is replaced by the Unitech HT630-A000BADG Mobile Computer.
Unitech HT630 - Unitech PT630D Portable Terminal - 2.5MB RAM - 256KB Flash - 2.3" LCD - 19 Keys
  • With batch connectivity, collect data immediately to your gadget and sync all the records to a computer afterward
  • Laser-free design provides high-performance scanning without the risk of eye injury
  • 2.50 MB RAM / 256 KB flash
  • 2.3" LCD screen is ideal for scan intensive applications
  • Alphanumeric keypad allows prompt data input
  • DOS OS offers free and complete DOS-compatible environment to run legacy softwares and support embedded systems
Read More

Need a different version? See all Unitech HT630 Mobile Computers

Discontinued See Replacement
Add to Quote
Add to My Shopping List Add to Compare
Unitech HT630-VB0A1G Mobile Computer
Unitech HT630-VB0A1G Mobile Computer Unitech HT630-VB0A1G Mobile Computer Unitech HT630-VB0A1G Mobile Computer
Unitech HT630-VB0A1G Mobile Computer
Unitech HT630-VB0A1G Mobile Computer

Full specifications (PDF)
Unitech HT630 Mobile Computer Model Overview
The Unitech HT630 Rugged Handheld Terminal is the one-stop shop for all 1D scanning. With either the 1D laser or CCD data collection solution, the HT630 is versatile, making it suitable in the supply chain, retail, and field service markets. All at an affordable price, the HT630 is both flexible and packs a high performance punch.
Unitech HT630-VB0A1G Mobile Computer Overview

The PT630D is designed to meet your demands in various applications, ranging from Transportation and Warehousing to Mobile Sales, Field Service, Retail, Meter Reading, etc.Rugged and durable, yet weighing less than 250 grams, the PT630D is easy to handle.The PT630D is well-protected by a robust housing allowing multiple 4 foot (1.2 meter) bounces off a concrete floor.

Full specifications (PDF)
Technical Information
Connectivity Technology:
Batch
Image Sensor Type:
CCD
Light Source:
LED
Scanner Range:
Long Range
Barcode Symbology Supported:
  • China Postal Code
  • Codabar
  • Code 39 Full ASCII
  • Code 39
  • Code 128
  • Code 93
  • EAN-13
  • EAN-8
  • EAN-128
  • Interleaved 2 of 5
  • ITF
  • UPC-E
  • UPC-A
Drop Specification:
48" To Concrete
Memory
Standard Memory:
2.50 MB
Flash Memory:
256 KB
Display & Graphics
Screen Size:
2.3"
Screen Resolution:
128 x 64
Display Color:
Monochrome
Display Screen Type:
LCD
Number of Lines:
8
Number of Characters:
20
Keyboard/Keypad
Number of Keys:
27
Keyboard Type:
Alphanumeric
Software
Operating System:
DOS
Battery Information
Battery Capacity:
900 mAh
Battery Chemistry:
Lithium Ion (Li-Ion)
Battery Included:
Yes
Physical Characteristics
Height:
6.6"
Width:
2.6"
Depth:
1.4"
Weight (Approximate):
8.60 oz
Miscellaneous
Package Contents:
  • PT630D Portable Terminal
  • A/C Adapter
  • Battery
  • RS232 Communication Cable
  • JobGen Plus Software
Additional Information:

Interface: RS232 Via Proprietary Cable

Certifications & Standards:
  • CE
  • FCC
Environmentally Friendly:
Yes
Environmental Certification:
RoHS
Warranty
Limited Warranty:
1 Year
Item Numbers
UNSPSC: 43211715
