Unitech HT630 – Mobile Computer

Part Number: HT630-AC0A1G
Model: HT630
Add to My Shopping List Add to Compare
Discontinued See Replacement

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Connectivity Technology
Batch
Light Source
Laser
Barcode Symbology Supported
China Postal CodeCodabarCode 39Code 39 Full ASCIICode 93Code 128EAN-8EAN-13EAN-128Interleaved 2 of 5ITFUPC-AUPC-E
Drop Specification
48" To Concrete

Product Description:

  Unitech PT630D Portable Terminal - 4.5MB RAM - 256KB Flash - Backlit LCD - 27 Keys
Explore all Unitech HT630 Mobile Computers
Add to Quote
Unitech HT630-AC0A1G Mobile Computer
Unitech HT630-AC0A1G Mobile Computer
Unitech HT630-AC0A1G Mobile Computer
Unitech HT630-AC0A1G Mobile Computer Unitech HT630-AC0A1G Mobile Computer

Full specifications (PDF)

Unitech HT630 Mobile Computer Model Overview

The Unitech HT630 Rugged Handheld Terminal is the one-stop shop for all 1D scanning. With either the 1D laser or CCD data collection solution, the HT630 is versatile, making it suitable in the supply chain, retail, and field service markets. All at an affordable price, the HT630 is both flexible and packs a high performance punch.
Unitech HT630-AC0A1G Mobile Computer Overview

The PT630D is designed to meet your demands in various applications, ranging from Transportation and Warehousing to Mobile Sales, Field Service, Retail, Meter Reading, etc.Rugged and durable, yet weighing less than 250 grams, the PT630D is easy to handle.The PT630D is well-protected by a robust housing allowing multiple 4 foot (1.2 meter) bounces off a concrete floor.

Full specifications (PDF)
Technical Information
Connectivity Technology:
Batch
Light Source:
Laser
Barcode Symbology Supported:
  • China Postal Code
  • Codabar
  • Code 39
  • Code 39 Full ASCII
  • Code 93
  • Code 128
  • EAN-8
  • EAN-13
  • EAN-128
  • Interleaved 2 of 5
  • ITF
  • UPC-A
  • UPC-E
Drop Specification:
48" To Concrete
Memory
Standard Memory:
4.50 MB
Flash Memory:
256 KB
Display & Graphics
Screen Resolution:
128 x 64
Display Color:
Monochrome
Display Screen Type:
LCD
Keyboard/Keypad
Number of Keys:
27
Keyboard Type:
Alphanumeric
Software
Operating System:
DOS
Battery Information
Battery Capacity:
900 mAh
Battery Chemistry:
Nickel Metal Hydride (NiMH)
Battery Included:
Yes
Physical Characteristics
Height:
6.6"
Width:
2.6"
Length:
1.4"
Weight (Approximate):
8.64 oz
Miscellaneous
Package Contents:
  • PT630D Portable Terminal
  • A/C Adapter
  • Battery
  • RS232 Communication Cable
  • JobGen Plus Software
Additional Information:
  • 16-bit 80188 compatible microprocessor
  • Interface: RS232 Via Proprietary Cable
  • Environmental sealing: IP54
Certifications & Standards:
  • CE
  • FCC
Environmentally Friendly:
Yes
Environmental Certification:
RoHS
Warranty
Limited Warranty:
1 Year
Item Numbers
UNSPSC: 43211715

Recommended Accessories

Category

  • Batteries (2)
  • Cables, Connectors, and Adapters (6)
  • Carrying and Protective Accessories (1)
  • Docks and Cradles (5)
  • General Software (1)
  • Mobile Computer Accessories (10)
  • Power Device (1)
  • Scan Engine (1)
  • Spare Parts (1)

Recommended Accessories for Model: Unitech HT630-AC0A1G Mobile Computer

Top Batteries Purchased With Unitech HT630-AC0A1G

Top Cables, Connectors, and Adapters Purchased With Unitech HT630-AC0A1G

See All Cables, Connectors, and Adapters for Unitech HT630-AC0A1G Mobile Computer >

Top Carrying and Protective Accessories Purchased With Unitech HT630-AC0A1G

Top Docks and Cradles Purchased With Unitech HT630-AC0A1G

See All Docks and Cradles for Unitech HT630-AC0A1G Mobile Computer >

Top General Software Purchased With Unitech HT630-AC0A1G

  • Unitech INVENLITE Software
    Unitech INVENLITE Software
    Lite Software for the HT630. The mobile device program allows for the following operations: Receiving, Item Transfer, Shipping, Audit, Asset Audit. The PC facing application allows you to upload batch collected data to the host PC and to generate simple reports. Includes installation and one hour of support.
