Unitech HT630 – Mobile Computer

Part Number: HT630-A000CADG
Model: HT630
Add to My Shopping List Add to Compare
Discontinued See Replacement

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Connectivity Technology
Batch
Light Source
Laser
Barcode Symbology Supported
UPC-A/EEAN-8/13CodabarCode 39Code 39 full ASCICode 93Code 32Interleaved 2 of 5Standard 2 of 5EAN 128Code 11DeltaMSI/PlesseyCode 128ToshibaEAN 128
Drop Specification
48" To Concrete

Product Description:

  Unitech HT630 Mobile Computer - 4.5MB RAM - 256KB Flash - 2.3"
Explore all Unitech HT630 Mobile Computers
Add to Quote
Unitech HT630-A000CADG Mobile Computer
Unitech HT630-A000CADG Mobile Computer
Unitech HT630-A000CADG Mobile Computer
Unitech HT630-A000CADG Mobile Computer Unitech HT630-A000CADG Mobile Computer

Full specifications (PDF)

Unitech HT630 Mobile Computer Model Overview

The Unitech HT630 Rugged Handheld Terminal is the one-stop shop for all 1D scanning. With either the 1D laser or CCD data collection solution, the HT630 is versatile, making it suitable in the supply chain, retail, and field service markets. All at an affordable price, the HT630 is both flexible and packs a high performance punch.
Unitech HT630-A000CADG Mobile Computer Overview

The HT630 mobile computer is designed to meet the demands of various applications, ranging from transportation and warehousing to mobile sales and retail. Rugged and durable, yet weighing less than 8 ounces,it is easy to handle.

Full specifications (PDF)
Technical Information
Connectivity Technology:
Batch
Light Source:
Laser
Barcode Symbology Supported:
  • UPC-A/E
  • EAN-8/13
  • Codabar
  • Code 39
  • Code 39 full ASCI
  • Code 93
  • Code 32
  • Interleaved 2 of 5
  • Standard 2 of 5
  • EAN 128
  • Code 11
  • Delta
  • MSI/Plessey
  • Code 128
  • Toshiba
  • EAN 128
Drop Specification:
48" To Concrete
Memory
Standard Memory:
4.50 MB
Flash Memory:
256 KB
Display & Graphics
Screen Size:
2.3"
Display Color:
Monochrome
Keyboard/Keypad
Number of Keys:
27
Keyboard Type:
Alphanumeric
Software
Operating System:
DOS
Battery Information
Battery Capacity:
900 mAh
Battery Chemistry:
Lithium Ion (Li-Ion)
Battery Included:
Yes
Physical Characteristics
Height:
6.6"
Width:
2.6"
Depth:
1.4"
Weight (Approximate):
8.60 oz
Miscellaneous
Package Contents:
  • HT630 Mobile Computer
  • USB Cable
  • AC Power
  • Battery
  • Manuals
  • Quick Start Guide
Additional Information:
  • CPU: 16-bit 80188
  • LED Graphic
  • Laser Type: Wide angle
Certifications & Standards:
  • Environmental Sealing: IP54
  • CE
  • FCC
Environmentally Friendly:
Yes
Environmental Certification:
RoHS
Warranty
Limited Warranty:
1 Year
Item Numbers
UNSPSC: 43211715

Recommended Accessories

Category

  • Batteries (2)
  • Cables, Connectors, and Adapters (6)
  • Carrying and Protective Accessories (1)
  • Docks and Cradles (5)
  • General Software (1)
  • Mobile Computer Accessories (10)
  • Power Device (1)
  • Scan Engine (1)
  • Spare Parts (1)

Recommended Accessories for Model: Unitech HT630-A000CADG Mobile Computer

Top Batteries Purchased With Unitech HT630-A000CADG

Top Cables, Connectors, and Adapters Purchased With Unitech HT630-A000CADG

See All Cables, Connectors, and Adapters for Unitech HT630-A000CADG Mobile Computer >

Top Carrying and Protective Accessories Purchased With Unitech HT630-A000CADG

Top Docks and Cradles Purchased With Unitech HT630-A000CADG

See All Docks and Cradles for Unitech HT630-A000CADG Mobile Computer >

Top General Software Purchased With Unitech HT630-A000CADG

  • Unitech INVENLITE Software
    Unitech INVENLITE Software
    Lite Software for the HT630. The mobile device program allows for the following operations: Receiving, Item Transfer, Shipping, Audit, Asset Audit. The PC facing application allows you to upload batch collected data to the host PC and to generate simple reports. Includes installation and one hour of support.
    Please Call for Pricing or to Purchase

Top Mobile Computer Accessories Purchased With Unitech HT630-A000CADG

See All Mobile Computer Accessories for Unitech HT630-A000CADG Mobile Computer >

Top Power Device Purchased With Unitech HT630-A000CADG

Top Scan Engine Purchased With Unitech HT630-A000CADG

Top Spare Parts Purchased With Unitech HT630-A000CADG

Questions? Get Help from
a Mobile Expert!

What is your operating system?

The Unitech HT630-A000CADG Mobile Computer is also known as UNI-HT630-A000CADG or HT6309000CADG.
