Features:
Fanless
Ubiquiti Networks USW-ULTRA Wireless Access Points
Part Number:
USW-ULTRA
Model:
Parts
Ubiquiti Networks UniFi Data Networking Model Overview
Ubiquiti UniFi Access Points provide business-class wireless coverage with cloud-ready, centralized control. The UniFi platform streamlines configuration, security policies, and network analytics across single or multi-location deployments. PoE support and versatile mounting options speed installation in new builds or retrofit environments. Perfect for enterprises, campuses, hotels, restaurants, and managed service providers seeking scalable, high-reliability Wi-Fi.
Technical Information
Interfaces/Ports
Total Number of Network Ports:
8
Stack Port:
No
Port/Expansion Slot Details:
- 7 x Gigabit Ethernet PoE+
- 1 x Gigabit Ethernet PoE++
Media & Performance
Media Type Supported:
Twisted Pair
Ethernet Technology:
Gigabit Ethernet
Network Technology:
1000Base-T
Network & Communication
Layer Supported:
2
Management & Protocols
Manageable:
Yes
Power Description
PoE (RJ-45) Port:
Yes
PoE Budget:
42 W
Input Voltage:
- 44 V
- 57 V
Power Source:
- Power Adapter
- DC
- Power Supply
Power Consumption:
9 W
Physical Characteristics
Product Material:
Polycarbonate
Form Factor:
Wall Mountable
Height:
1.3"
Width:
8"
Depth:
3"
Weight (Approximate):
11.29 oz
Miscellaneous
Application/Usage:
- IP Camera
- VoIP Phone
- Wireless Access Point
- Office
- Network
Item Numbers
GTIN:
0810084693698
UPC:
810084693698
EAN:
0810084693698
UNSPSC:
43222612
Frequently Asked Questions
What are the key networking specifications of the Ubiquiti Networks USW-ULTRA?
The USW-ULTRA is a manageable access point featuring 8 Gigabit Ethernet ports with 1000Base-T connectivity and Layer 2 support. It operates on twisted pair cabling and includes PoE (Power over Ethernet) ports, making it ideal for enterprise deployments where network infrastructure needs to be centrally powered and managed.
What is the power consumption and PoE budget for the USW-ULTRA?
The USW-ULTRA has a power consumption of 9W and provides a 42W PoE budget. This PoE budget allows you to power connected devices directly through the Ethernet ports, reducing the need for separate power supplies and simplifying installation in warehouse and logistics environments.
Is the Ubiquiti Networks USW-ULTRA suitable for wall mounting?
Yes, the USW-ULTRA is wall mountable, making it flexible for deployment in various facility layouts. This feature is particularly useful in warehouses and distribution centers where space optimization and cable management are important considerations.
What wireless standards does the USW-ULTRA support?
The USW-ULTRA supports simultaneous dual-band operation with 802.11 b/g/n on the 2.4 GHz frequency and 802.11 a/n on the 5 GHz frequency. This dual-band capability ensures compatibility with a wide range of wireless devices and helps reduce interference in high-density warehouse environments.
What operating conditions should I expect for the USW-ULTRA?
The USW-ULTRA operates reliably in temperatures ranging from -5 to 40°C (23 to 104°F) with operating humidity between 5 to 95% noncondensing. These environmental specifications make it suitable for both climate-controlled indoor facilities and temperature-variable warehouse environments.
What certifications does the Ubiquiti Networks USW-ULTRA hold?
The USW-ULTRA carries CE, FCC, and IC certifications, ensuring compliance with regulatory standards across North America and Europe. Contact us today to verify certification requirements for your specific deployment region.
The Ubiquiti Networks USW-ULTRA Wireless Access Points is also known as
UBI-USWULTRA
