Ubiquiti Networks UAP-AC-LITE-5-US Data Networking

Part Number: UAP-AC-LITE-5-US
Model: Parts
Add to My Shopping List Add to Compare
$514.09
Item on backorder — chat for lead time

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Wireless LAN Standard
IEEE 802.11ac
Frequency Band
2.40 GHz5 GHz
Total Number of Antennas
2
Number of Internal Antennas
2

Product Description:

  Ubiquiti UniFi UAP-AC-LITE IEEE 802.11ac 867 Mbit/s Wireless Access Point - 2.40 GHz, 5 GHz - MIMO Technology - 1 x Network (RJ-45) - Ethernet, Fast Ethernet, Gigabit Ethernet - Wall Mountable, Ceiling Mountable - 5 Pack.
Explore all Ubiquiti Networks Parts Accessories
Add to Quote
Ubiquiti Networks UAP-AC-LITE-5-US Data Networking
Ubiquiti Networks UAP-AC-LITE-5-US Data Networking
Ubiquiti Networks UAP-AC-LITE-5-US Data Networking
Ubiquiti Networks UAP-AC-LITE-5-US Data Networking
Ubiquiti Networks UAP-AC-LITE-5-US Data Networking
Ubiquiti Networks UAP-AC-LITE-5-US Data Networking
Ubiquiti Networks UAP-AC-LITE-5-US Data Networking
Ubiquiti Networks UAP-AC-LITE-5-US Data Networking
Ubiquiti Networks UAP-AC-LITE-5-US Data Networking Ubiquiti Networks UAP-AC-LITE-5-US Data Networking Ubiquiti Networks UAP-AC-LITE-5-US Data Networking Ubiquiti Networks UAP-AC-LITE-5-US Data Networking Ubiquiti Networks UAP-AC-LITE-5-US Data Networking Ubiquiti Networks UAP-AC-LITE-5-US Data Networking Ubiquiti Networks UAP-AC-LITE-5-US Data Networking Ubiquiti Networks UAP-AC-LITE-5-US Data Networking
Technical Information
Wireless LAN Standard:
IEEE 802.11ac
Frequency Band:
  • 2.40 GHz
  • 5 GHz
Total Number of Antennas:
2
Number of Internal Antennas:
2
Wireless Transmission Speed:
867 Mbit/s
MIMO Technology:
Yes
Interfaces/Ports
Ethernet Technology:
  • Ethernet
  • Fast Ethernet
  • Gigabit Ethernet
Number of Network (RJ-45) Ports:
1
PoE (RJ-45) Port:
No
PoE PD Port:
Yes
VGA:
No
HDMI:
No
USB:
No
Powerline:
No
Management Port:
No
Physical Characteristics
Form Factor:
  • Wall Mountable
  • Ceiling Mountable
Height:
1.2"
Width:
6.3"
Diameter:
6.3"
Weight (Approximate):
6 oz
Miscellaneous
Package Contents:
  • UniFi UAP-AC-LITE Wireless Access Point
  • Wall/Ceiling Kits
Country of Origin:
China
Warranty
Limited Warranty:
1 Year
Item Numbers
GTIN: 0022167803492, 0079643951871, 0810354024030, 0818213980152
UPC: 022167803492, 079643951871, 810354024030, 818213980152
EAN: 0022167803492, 0079643951871, 0810354024030, 0818213980152
UNSPSC: 43222631

Frequently Asked Questions

The UAP-AC-LITE supports 802.11 a/b/g/n/ac standards, delivering wireless speeds up to 867 Mbps on the 802.11ac band. This dual-band access point operates on both 2.4 GHz and 5 GHz frequencies, making it compatible with a wide range of wireless devices. We offer this model as part of our Ubiquiti networking solutions for enterprise and high-density deployments.

The UAP-AC-LITE can support 250+ concurrent clients, with up to four BSSIDs per radio for network segmentation and guest access. This capacity makes it suitable for warehouse, retail, and office environments requiring reliable multi-user connectivity. Contact us today to discuss deployment sizing for your facility.

The UAP-AC-LITE operates via Passive Power over Ethernet (24V) and draws a maximum of 6.5W during operation. A 24V, 0.5A Gigabit PoE adapter is included with single-pack units, though 5-packs require separate PoE infrastructure. This low power consumption makes it ideal for energy-efficient network deployments available from us.

The UAP-AC-LITE is designed for both wall and ceiling mounting, with included mounting kits for easy installation in any orientation. Its compact dimensions of 160 x 160 x 31.45 mm (6.30 x 6.30 x 1.24") and lightweight design at 170g make it suitable for diverse facility layouts. Visit barcodesinc.com to order your units with full mounting hardware included.

Yes, the UAP-AC-LITE includes advanced traffic management features such as 802.1Q VLAN support, per-user rate limiting, guest traffic isolation, and WMM quality of service prioritization for voice, video, best effort, and background traffic. Wireless security is supported through WEP, WPA-PSK, and WPA-Enterprise (WPA/WPA2 with TKIP/AES encryption). These enterprise-grade features are available in the 5-pack we offer for larger deployments.

The UAP-AC-LITE operates reliably in temperatures ranging from -10 to 70°C (14 to 158°F) and humidity levels of 5 to 95% noncondensing, making it suitable for both indoor and semi-outdoor warehouse and logistics environments. The unit is certified by CE, FCC, and IC regulatory bodies. Contact us today for guidance on environmental suitability for your specific deployment location.

The Ubiquiti Networks UAP-AC-LITE-5-US Data Networking is also known as UBI-UAPACLITE5US
