Ubiquiti Networks U-POE Wireless Access Points
Ubiquiti Networks UniFi Data Networking Model Overview
Ubiquiti UniFi Access Points provide business-class wireless coverage with cloud-ready, centralized control. The UniFi platform streamlines configuration, security policies, and network analytics across single or multi-location deployments. PoE support and versatile mounting options speed installation in new builds or retrofit environments. Perfect for enterprises, campuses, hotels, restaurants, and managed service providers seeking scalable, high-reliability Wi-Fi.
Frequently Asked Questions
What power specifications does the Ubiquiti U-POE++ Injector provide?
The U-POE++ Injector delivers 60W of power output at 48V DC with a maximum current of 1.25A. It accepts both 120V AC and 230V AC input, making it suitable for various electrical environments. This injector features a single RJ-45 input port and one PoE++ output port for powering compatible access points.
Is the U-POE++ Injector compatible with UniFi access points?
Yes, the U-POE++ Injector is compatible with Ubiquiti UniFi access points that support PoE++ power. UniFi models including UAP, UAP-LR, and UAP-PRO can be powered using a PoE injector. To enable PoE output power, you must select Power Source > PoE Injector in UniFi Controller.
What are the operating temperature and humidity ranges for the U-POE++ Injector?
The U-POE++ Injector operates reliably in temperatures from -20°C to 60°C (-4°F to 140°F) and humidity levels from 5% to 90% noncondensing. For storage, the device can withstand temperatures ranging from -30°C to 70°C (-22°F to 158°F).
How many ports does the U-POE++ Injector have?
The U-POE++ Injector features one RJ-45 input port for receiving network data and one PoE++ output port for delivering power and data to your access point. This single-port design makes it ideal for powering individual access points in your network.
What is the efficiency rating of the U-POE++ Injector?
The U-POE++ Injector delivers greater than 86% efficiency, ensuring minimal power loss during operation. It also maintains excellent voltage regulation with less than 1% line regulation and less than 3% load regulation for stable power delivery.
Can the U-POE++ Injector be used in outdoor installations?
The U-POE++ Injector is designed for controlled environments with operating humidity limits of 5% to 90% noncondensing and operating temperatures from -20°C to 60°C. For outdoor access point deployments, we recommend consulting our team about proper installation and environmental protection. Contact us today for guidance on your specific outdoor networking requirements.
