Network (RJ-45):
Yes
Ubiquiti Networks U-LTE-US Network Antennas
Part Number:
U-LTE-US
Model:
Parts
Interfaces/Ports
Network & Communication
Ethernet Technology:
Gigabit Ethernet
Physical Characteristics
Height:
8"
Width:
2.6"
Depth:
1.3"
Weight (Approximate):
7.05 oz
Miscellaneous
Additional Information:
- Weight With Mounting: 316 g (11.15 oz)
- Max Power Consumption: 8.5W
- Power Method: 802.3at (Pairs 1, 2+; 3, 6-; Pairs 4, 5+; 7, 8-))
- Power Supply: UniFi PoE Switch
- Voltage Range: 44 to 57VDC
- LCM: 1.54" Display
- LTE Category: Cat 4
- LTE Bands: B2/4/5/12
- LTE Antenna: (1) 2x2
- Operating Frequency: 2400 - 2483.5 MHz
- Mounting: Wall, Desktop
- Operating Temperature: -10 to 50° C (14 to 122° F)
- Operating Humidity: 5 to 95% Noncondensing
Certifications & Standards:
- FCC
- IC
- PTCRB
- AT&T
Country of Origin:
China
Warranty
Limited Warranty:
2 Year
Item Numbers
GTIN:
0817882027908, 0999555988027, 0999556686922
UPC:
817882027908, 999555988027, 999556686922
EAN:
0817882027908, 0999555988027, 0999556686922
UNSPSC:
43222628
Frequently Asked Questions
What networking interfaces and connectivity options does the Ubiquiti U-LTE-US provide?
The U-LTE-US features one 100/1000 SFP port for high-speed connectivity. It supports multiple interface and encapsulation types including Ethernet, 802.1q VLAN, PPPoE, GRE, and IP in IP, making it flexible for various network configurations. The device also includes passive PoE with a 24VDC power adapter, delivering up to 12W per data/PoE output port with a combined maximum of 50W across all 5 data ports.
What VPN and security features are included with this Ubiquiti router?
The U-LTE-US runs EdgeOS and includes comprehensive security features such as ACL-based and zone-based firewalls, NAT, and multiple VPN options including IPSec, OpenVPN, PPTP, and L2TP for both site-to-site and remote access scenarios. These capabilities make it suitable for secure enterprise deployments requiring redundant WAN connectivity over LTE.
Can the Ubiquiti U-LTE-US be mounted on poles or walls?
Yes, the U-LTE-US supports both pole and wall mounting. It is engineered to withstand wind loading of 153 N at 200 km/h (34 lbf at 125 mph) and has wind survivability rated to 200 km/h (125 mph), making it suitable for outdoor deployment in challenging environments.
What are the operating temperature and humidity ranges for the U-LTE-US?
The U-LTE-US is rated for operating temperatures between -40 to 65°C (-40 to 149°F) and operating humidity of 10 to 90% noncondensing. These specifications make it suitable for deployment in diverse climate conditions, from cold outdoor installations to warm industrial environments.
What routing and QoS capabilities does the U-LTE-US offer?
The U-LTE-US supports advanced routing protocols including static routes, OSPF/OSPFv3, RIP/RIPng, and BGP with IPv6 support, plus IGMP proxy functionality. For quality of service, it offers multiple QoS options including FIFO, Stochastic Fairness Queueing, Random Early Detection, Token Bucket Filter, Deficit Round Robin, Hierarchical Token Bucket, and ingress policing to manage network traffic effectively.
What management and monitoring options are available for the U-LTE-US?
The U-LTE-US provides multiple management interfaces including a web UI, CLI (console, SSH, Telnet), SNMP, NetFlow, LLDP, NTP, UBNT Discovery Protocol, and logging capabilities. These tools enable comprehensive network monitoring and remote management for IT teams overseeing redundant WAN deployments.
The Ubiquiti Networks U-LTE-US Network Antennas is also known as
UBI-ULTEUS
