What is the maximum throughput speed of the Ubiquiti R5AC-Lite?
The Ubiquiti Rocket ac R5AC-Lite delivers up to 500+ Mbps throughput using airMAX ac technology. This performance is achieved through the airMAX Engine with custom IC processing, making it suitable for high-speed point-to-point and point-to-multipoint wireless links.
What wireless standards and data rates does the R5AC-Lite support?
The R5AC-Lite supports IEEE 802.11ac with MIMO technology and operates on the 5 GHz band. It offers selectable channel widths of 10/20/30/40/50/60/80 MHz for point-to-point mode and 10/20/30/40 MHz for point-to-multipoint mode, providing flexible deployment options based on your network requirements.
What are the power and connectivity specifications for the R5AC-Lite?
The R5AC-Lite features a single 10/100/1000 Gigabit Ethernet (RJ-45) port for network connectivity and operates with a 24V Gigabit PoE power supply. Maximum power consumption is 9.5W, and it supports passive PoE using pairs 4, 5+ and 7, 8 for power delivery.
Is the R5AC-Lite suitable for outdoor deployment?
Yes, the R5AC-Lite is designed for outdoor wireless deployment with an operating temperature range of -40 to 80°C (-40 to 176°F) and operating humidity of 5 to 95% noncondensing. The device features a die-cast aluminum enclosure with white powder coating and includes ESD/EMP protection rated at ±24 kV contact/air for the Ethernet port.
What security features does the R5AC-Lite provide?
The R5AC-Lite provides the strongest WPA2 AES security encryption to protect your wireless network. It runs on airOS 8, Ubiquiti's revolutionary operating system, which includes comprehensive security features and diagnostic tools for enterprise-grade network management.
What antennas are compatible with the R5AC-Lite?
The R5AC-Lite is designed to pair with airMAX ac antennas for optimal performance. For point-to-point backhaul links, it works with the RocketDish ac antenna, while point-to-multipoint deployments use the airMAX ac Sector antenna. Contact us today to find the right antenna configuration for your deployment.
