What is the maximum outdoor range of the Ubiquiti PowerBeam PBE-M5-400?
The PBE-M5-400 delivers a maximum outdoor range of 15.5 miles, making it ideal for long-distance point-to-point wireless bridging in warehouse and logistics environments. This extended range is achieved through its 25 dBi antenna gain and 5 GHz operating frequency.
What are the networking specifications and throughput of the PBE-M5-400?
The PBE-M5-400 features a single Gigabit Ethernet port (10/100/1000) and delivers 150+ Mbps throughput. It supports flexible channel sizes from 5 to 40 MHz and dual linear polarization for reliable data transmission in warehouse and logistics operations.
How is the PBE-M5-400 powered and what are its power requirements?
The PBE-M5-400 uses passive PoE (Power over Ethernet) with a 24V, 0.5A Gigabit PoE power supply, supporting a voltage range of 18-26VDC. Maximum power consumption is only 8W, making it energy-efficient for outdoor deployments.
What environmental conditions can the PBE-M5-400 withstand?
The PBE-M5-400 is engineered for harsh outdoor environments with an operating temperature range of -40 to 70°C, operating humidity of 5 to 95% non-condensing, and wind survivability up to 200 km/h (125 mph). Its galvanized steel dish and powder-coated brackets with GEOMET-coated fasteners provide superior corrosion resistance.
What mounting options and mechanical features does the PBE-M5-400 offer?
The PBE-M5-400 includes a pole-mount kit and features innovative mechanical design with built-in tilt capability offering 20° of uptilt and up to 20° of downtilt. The antenna feed detaches with a push button for easy removal, and the mounting bracket design simplifies assembly and installation.
Can the PBE-M5-400 be centrally managed with other Ubiquiti devices?
Yes, the PBE-M5-400 can be managed through Ubiquiti's centralized management system, which allows operators to monitor device status, perform mass firmware upgrades, access the web UI, manage groups of devices, and schedule tasks across your entire network. Contact us today to discuss deployment options available from Barcodes Inc.
