What is the maximum outdoor range of the Ubiquiti PBE-5AC-500?
The Ubiquiti PowerBeam ac PBE-5AC-500 delivers a maximum outdoor range of 15.5 miles, making it ideal for long-distance point-to-point wireless bridge deployments in warehouse and logistics environments. This extended range is achieved through its 27 dBi directional antenna gain and 802.11ac 5 GHz technology.
What are the power and connectivity requirements for the PBE-5AC-500?
The PBE-5AC-500 requires 24V, 0.5A Gigabit PoE power delivery (passive PoE on pairs 4, 5+ and 7, 8 return) with a maximum power consumption of 8W. It features one 10/100/1000 Gigabit Ethernet port for network connectivity, supporting fast and gigabit ethernet speeds.
Is the PBE-5AC-500 suitable for outdoor installation in harsh environments?
Yes, the PBE-5AC-500 is engineered for outdoor deployment with an outdoor UV-stabilized plastic enclosure, operating temperature range of -40 to 70°C, and operating humidity tolerance of 5 to 95% noncondensing. It also features ESD/EMP protection (±24 kV air and contact) and passes salt fog testing per IEC 68-2-11, making it suitable for demanding logistics and warehouse installations.
What wireless frequencies and channel sizes does the PBE-5AC-500 support?
The PBE-5AC-500 operates on 5 GHz frequencies (5150–5875 MHz worldwide) and supports channel sizes of 10/20/30/40/50/60/80 MHz in point-to-point mode and 10/20/30/40 MHz in point-to-multipoint mode. It is FCC, IC, and CE certified for regulatory compliance across multiple regions.
How does the PBE-5AC-500 handle wind and extreme weather conditions?
The PBE-5AC-500 is rated for wind survivability up to 200 km/h (125 mph) with a wind loading capacity of 984 N at 200 km/h. Its pole-mount kit is included for secure installation, and the device includes built-in mechanical downtilt adjustment of ±20° for flexible antenna positioning in outdoor deployments.
What mounting and installation options are available for the PBE-5AC-500?
The PBE-5AC-500 is pole-mountable and includes a pole-mount kit with your purchase. The device measures 564 x 564 x 308 mm and weighs 5.2 kg, making it suitable for rooftop and elevated installations common in warehouse and logistics network deployments. Contact us today for installation support and guidance.
