The NBE-2AC-13 is an IEEE 802.11ac wireless bridge operating at 2.40 GHz with a 330 Mbit/s data rate and 13 dBi gain. It features a single Gigabit Ethernet port (10/100/1000), supports channel sizes from 5 to 40 MHz, and includes dual linear polarization for flexible deployment in point-to-point or point-to-multipoint configurations.
The NBE-2AC-13 supports pole-mount, wall-mount, and window-mount installation options. A pole-mount kit is included with the unit, and optional window-mount accessories are available to expand deployment flexibility across warehouse, facility, and outdoor perimeter installations.
The NBE-2AC-13 consumes a maximum of 6W and is powered via 24V, 0.5A PoE (Power over Ethernet). This allows for simplified installation using a single Ethernet cable for both data and power delivery, reducing infrastructure requirements in warehouse and logistics environments.
The NBE-2AC-13 is engineered for extreme environments with an operating temperature range of -40 to 80°C (-40 to 176°F), operating humidity of 5 to 95% noncondensing, and wind survivability up to 200 km/h (125 mph). It features an outdoor UV-stabilized plastic enclosure and has passed rigorous testing including salt fog, vibration, temperature shock, UV exposure, and wind-driven rain per IEC and MIL standards.
The NBE-2AC-13 is equipped with an Atheros MIPS 74Kc processor running at 560 MHz, 64 MB of DDR2 memory, and 8 MB of Flash storage. These specifications support reliable management and data throughput for wireless bridge operations in logistics and warehouse applications.
The NBE-2AC-13 is FCC, IC, and CE certified for wireless operation and is RoHS compliant. It also includes ESD/EMP protection rated at ±24 kV (air and contact), ensuring safe operation in environments with electrical equipment and electromagnetic interference common in industrial and warehouse settings.
