What are the networking specifications of the Ubiquiti ES-16XP?
The Ubiquiti ES-16XP is a 16-port managed Ethernet switch featuring (12) 1/10 Gbps SFP+ ports and (4) 1/10 Gbps RJ45 Ethernet ports, delivering 18 Gbps of non-blocking throughput. It supports Layer 2 and Layer 3 switching with a switching capacity of 320 Gbps and a forwarding rate of 238.10 Mpps, making it suitable for growing network infrastructure.
Can the ES-16XP be rack-mounted in a data center?
Yes, the ES-16XP is 1U rack-mountable and includes rack-mount brackets. With dimensions of 443 x 221 x 43 mm (17.44 x 8.70 x 1.69") and a weight of 2.71 kg with brackets, it fits standard 19-inch server racks for efficient data center deployment.
What management options are available for the ES-16XP?
The ES-16XP offers both graphical and command-line management interfaces. Administrators can use the EdgeSwitch Configuration Interface for convenient GUI-based management, or access advanced CLI functionality through the serial console port, telnet, or SSH for more granular control.
What advanced switching features does the ES-16XP support?
The ES-16XP supports comprehensive Layer 2 and Layer 3 features including MSTP/RSTP/STP, VLAN and Private VLAN support, Link Aggregation, DHCP Snooping, IGMP Snooping, 802.1X authentication, MAC filtering, ACL, DiffServ, CoS, static routing, policy-based routing, and DHCP server functionality.
What power options does the ES-16XP offer?
The ES-16XP supports dual power input methods: AC power (100-240VAC/50-60 Hz with internal 56W DC power supply) and DC power (25-16VDC with 2.5mm connector, available in redundant or stand-alone configurations). Maximum power consumption is 36W excluding SFP/SFP+ modules.
Is the ES-16XP suitable for connecting to 10G network infrastructure?
Yes, the ES-16XP is designed for 10G connectivity with (4) 10G RJ45 ports and (12) SFP+ ports that support 1/10 Gbps speeds. This allows you to connect to 10G routers, network-attached storage devices, and other EdgeSwitch units via fiber or copper, making it ideal for high-speed network expansion.
The Ubiquiti Networks ES-16XP Data Networking is also known as
UBI-ES16XP
