TSC 99-128A002-00LF Barcode Printer


0.0

(No reviews)

Be the first to

Write a Review
TSC TDP-345 - Direct thermal TDP-345, Includes USB, Serial, Parallel, 203 dpi, 5 IPS, TSPL-EZ, USB Cable included.
$444.50
In Stock:
Ships Same Day
Your satisfaction is guaranteed!
We want to make sure you are completely satisfied with your purchase. Customers must return their product within 30 days of shipment to receive a full credit less a 15% restocking fee. Returns must be presented in new condition with all of the original packaging.
Share:
Best-in-class price-performance in a compact platform.

The TSC TDP-345 offers high resolution 300 dpi printing at speeds up to 5 ips. The TDP-345 comes standard with USB, parallel and serial connections. Other options include an internal Ethernet interface for easy network integration, label cutters, and a keyboard for printing labels in standalone or down-time situations. The TDP-345 is ideally suited for product marking, shipping, retail and other labeling applications.

Technical Information

  • Maximum Mono Print Speed: 5 in/s
  • Maximum Print Resolution: 300 dpi
  • Print Color: Monochrome
  • Maximum Print Width: 4.17"
  • Recommended Use: Label Print
  • Barcode Symbology Supported:
    • Code 39
    • Code 93
    • Code 128
    • UCC
    • Code 128-A
    • Code 128-B
    • Code 128-C
    • Codabar
    • Interleaved 2 of 5
    • EAN-8
    • EAN-13
    • EAN 128
    • UPC-A
    • UPC-E
    • EAN With 2 or 5 Digit Extension
    • UPC 2 and 5 Digit Addendums
    • MSI
    • Plessey
    • POSTNET
    • RSS-14
    • GS1 DataBar
    • Code 11
    • China Post
    • PDF-417
    • Maxi Code
    • Data Matrix
    • QR Code
    • Aztec Code
    • RSS Stacked

General Information

  • Product Type: Direct Thermal Printer
  • Product Series: TDP
  • Brand Name: TSC Auto ID
  • Manufacturer: TSC Auto ID Technology Co., Ltd
  • Product Model: TDP-345
  • Product Name: TDP-345 Label Printer

Physical Characteristics

  • Height: 6.5"
  • Width: 7.9"
  • Depth: 9.5"
  • Form Factor: Desktop
  • Color: White

Interfaces/Ports

  • USB: Yes
  • Serial Port: Yes
  • Parallel Port: Yes

Other

  • Platform Supported: PC
  • Package Contents:
    • TDP-345 Label Printer
    • Software and Driver CD
    • Quick Start Guide
    • USB Cable
    • External Universal Switching Power Supply
    • Power Cord
    • Label Spindle
    • 2 x Fixing Tab
    • 2 x 1.5" Core Adapter
    • TDP-345 Label Printer
    • Software and Driver CD
    • Quick Start Guide
    • USB Cable
    • External Universal Switching Power Supply
    • Power Cord
    • Label Spindle
    • 2 x Fixing Tab
    • 2 x 1.5" Core Adapter
  • Certifications & Standards:
    • FCC Class B
    • CE Class B
    • C-Tick Class B
    • UL
    • CUL
    • TUV/Safety
    • CCC

Media Types & Handling

  • Maximum Label Width: 4.40"
  • Maximum Label Length: 40"
  • Media Type:
    • Continuous Label
    • Die-cut Label
    • Black Mark
    • Fanfold
    • Notch
  • Media Thickness: 190 mil
  • Media Sensor:
    • Cover Open Sensor
    • Reflective Media Sensor
    • Transmissive Media Sensor
  • Label Core Size: 3"
  • Maximum Roll Diameter: 8.40"

Memory

  • Standard Memory: 8 MB
  • Memory Card Slot: Yes
  • Memory Card Supported: Secure Digital
  • Memory Technology: SDRAM
  • Flash Memory: 4 MB

Power Description

  • Input Voltage:
    • 110 V AC
    • 220 V AC
  • Power Source: AC Supply

Warranty

  • Limited Warranty: 2 Year

Fonts & Emulation

  • Language Emulation: TSPL-EZ

Full specifications (PDF)

Full specifications (PDF)

Brand TSC
Model TDP-345
Print Method Direct Thermal
Interface Options Serial, Parallel, USB
Printer Type Desktop
Print Speed 5
Label Core 1 inch
Max Roll Outer Diameter 5
Print Resolution 300 dpi
Max Label Width 4.40
Maximum Print Width 4.17
Printer Mobility Not Mobile
