Tripp-Lite SU750XL Power Device

Tripp-Lite - Tripp Lite UPS Smart Online 750VA 600W Tower 100V/110V/120V USB DB9 SNMP RT - 750VA/600W - 4 Minute Full Load - 6 x NEMA 5-15R
  • 750VA / .75kVA / 600 watt on-line double-conversion tower UPS
  • 100/110/120V +/-2% output at 50/60Hz, high efficiency economy mode option
  • Expandable runtime, Hot-swappable battery modules
  • USB, RS232 & EPO ports; support for SNMP/WEB card options
  • Front panel status LEDs with detailed load and battery metering
  • 2 independently switchable output load banks
  • NEMA 5-15P input; 5-15R outlets
Read More

Need a different version? See all Tripp-Lite Parts Accessories

$811.97
Add to Quote
Add to My Shopping List Add to Compare
Tripp-Lite SU750XL Power Device
Tripp-Lite SU750XL Power Device Tripp-Lite SU750XL Power Device
Tripp-Lite SU750XL Power Device
Tripp-Lite SU750XL Power Device
Tripp-Lite Parts Accessory Model Overview
Products and parts from Tripp-Lite.
Tripp-Lite SU750XL Power Device Overview

The SU750XL on-line, double-conversion UPS protects critical server, networking or telecommunications equipment from blackouts, brownouts, voltage fluctuations and surges. Large-capacity 750VA/600W UPS continuously converts incoming AC to DC, then back to perfect sine wave AC output at 120V AC (+/-2%). Includes 6 UPS supported outlets; 2 single-outlet load banks can be independently controlled via a software interface to selectively reboot remote equipment or shed less critical loads. Includes slot for internal SNMP/WEB card, plus DB9 enhanced serial monitoring port for unattended shutdown, remote control and monitoring of UPS system and power data. Includes USB and DB9 serial ports. Built-in DB9 port offers both enhanced RS-232 enabled monitoring data, plus contact closure monitoring ability. HID-compliant USB interface enables integration with built-in power management and auto shutdown features of Windows and Mac OS X. Includes Tripp Lite's PowerAlert UPS power management software.

Technical Information
Plug/Connector Type:
NEMA 5-15P
Receptacle Type:
NEMA 5-15R
Receptacle Detail:
6 x NEMA 5-15R
Dataline Protection:
RJ-45
Bypass Switch:
Automatic
Emergency Power OFF:
Yes
Power Description
Load Capacity:
750 VA/600 W
Input Voltage:
110 V AC
Output Voltage:
120 V AC
Input Current:
6.20 A
Management
Network Management:
SNMP Manageable
Interfaces/Ports
Serial Port:
Yes
USB:
Yes
Battery Information
Backup/Run Time (Full Load):
4 Minute
Backup/Run Time (Half Load):
11 Minute
Typical Battery Recharge Time:
6 Hour
Hot Swappable:
Yes
Physical Characteristics
Height:
10"
Width:
6.8"
Depth:
13.3"
Form Factor:
Tower
Weight (Approximate):
28.70 lb
Miscellaneous
Package Contents:
  • SmartOnline SU750XL Tower UPS
  • SU750XL UPS System
  • PowerAlert Software CD and cabling
  • EPO (Emergency Power Off) cabling
  • Owner's manual with warranty information
Additional Information:
  • Switches: Includes combination main power on/test and main power off switch
Certifications & Standards:
Tested to UL1778 (USA), CSA C22.2 No. 107.3 (Canada), Class B (Emissions), RoHS-compliant, FCC Part 68/ Industry Canada (telecommunications)
Software Included:
PowerAlert Software
Country of Origin:
China
Warranty
Limited Warranty:
2 Year
Item Numbers
GTIN: 0027242522299, 0037332126160, 0818242019656
UPC: 027242522299, 037332126160, 818242019656
EAN: 0027242522299, 0037332126160, 0818242019656
UNSPSC: 39121011
