Tripp-Lite SMX3000XLRT2UA Power Device

Part Number: SMX3000XLRT2UA
Model: Parts
to get Free Ground Shipping on your order.
$2,609.68
In Stock

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Plug/Connector Type
IEC 60320 C20
Receptacle Type
IEC 60320 C13IEC 60320 C19
Receptacle Detail
8 x IEC 60320 C131 x IEC 60320 C19
Protection Type
BrownoutOver VoltageUnder VoltageEMI / RFIBlack OutSurge

Product Description:

  Tripp Lite UPS Smart 3000VA 2700W International Rackmount AVR 230V Pure Sine Wave C13 C19 TAA - 2U Rack/Tower - 5 Hour Recharge - 3.90 Minute Stand-by - 230 V AC Input - 8 x IEC 60320 C13, 1 x IEC 60320 C19

Tripp-Lite Parts Accessory Model Overview

Products and parts from Tripp-Lite.
Tripp-Lite SMX3000XLRT2UA Power Device Overview

Tripp Lite SmartPro Line Interactive UPS with enhanced LCD interface offers network-grade power protection for critical server, network and telecommunications equipment. Line Interactive Uninterruptible Power Supply (UPS) with built-in Auto-Voltage Regulation (AVR) actively corrects brownouts and overvoltages back to usable levels while maintaining a full battery charge in case of power failure. Tripp Lite's unique configuration excels in exceptionally poor-power environments with two separate levels of voltage boost to correct both slight undervoltages and severe brownout conditions. Interactive LCD interface reports UPS operating mode, detailed UPS and site-power data, plus enables a variety of UPS setup and configuration options. Super-fast switchover from line to battery power occurs within milliseconds to maintain operation of connected equipment without interruption or reboot. 98% line-mode efficiency offers reduced heat emissions and operating costs. Network management interfaces support communications via USB, RS-232 and optional SNMPWEBCARD network interface. HID-compliant USB interface enables integration with built-in power management and auto shutdown features of Windows and Mac OS X. Network communications ports enable detailed monitoring of equipment load levels, self-test data and utility power conditions. Includes PowerAlert monitoring software and complete cabling. Switched output load banks enable scheduled and real-time remote reboot and load shedding of select outlets. Emergency Power Off (EPO) interface. LCD display panel easily rotates for viewing in rackmount or tower configurations. Audible alarm with push-button momentary alarm-cancel and silent-mode configuration options. Programmable self-test. Field-replaceable, hot-swappable battery modules.

Technical Information
Plug/Connector Type:
IEC 60320 C20
Receptacle Type:
  • IEC 60320 C13
  • IEC 60320 C19
Receptacle Detail:
  • 8 x IEC 60320 C13
  • 1 x IEC 60320 C19
Protection Type:
  • Brownout
  • Over Voltage
  • Under Voltage
  • EMI / RFI
  • Black Out
  • Surge
Emergency Power OFF:
Yes
Power Description
Load Capacity:
3000 VA/2700 W
Input Voltage:
230 V AC
Output Voltage:
230 V AC
Input Current:
14.10 A
Waveform Type:
Sine Wave
Surge Energy Rating:
350 J
Management
Network Management:
SNMP Manageable
Alarm:
  • Power Failure
  • Low Battery
  • Overload
  • UPS Fault
  • Remote Shutdown
  • UPS StartUp
Controls/Indicators
Status Indicators:
Front panel LCD information and configuration screen offers detailed UPS and site power status and operating data, plus configuration of voltage, operating mode, alarm function and a variety of additional options
Interfaces/Ports
Serial Port:
Yes
USB:
Yes
Battery Information
Backup/Run Time (Full Load):
3.90 Minute
Backup/Run Time (Half Load):
11.10 Minute
Typical Battery Recharge Time:
5 Hour
Hot Swappable:
Yes
Environmental Conditions
Maximum Operating Temperature:
104°F (40°C)
Thermal Dissipation:
46.31 W
Physical Characteristics
Height:
3.5"
Width:
17.5"
Depth:
19.5"
Rack Height:
2U
Form Factor:
Rack/Tower
Weight (Approximate):
62.80 lb
Miscellaneous
Package Contents:
  • SMX3000XLRT2UA UPS System
  • PowerAlert Software CD
  • 4 Post Rackmount Installation Kit
  • 3 x C13/C14 Power Cables
  • Instruction Manual
  • USB Cable
  • DB9 Cable
  • EPO Cable
Certifications & Standards:
  • CE
  • IEC 62040-1
  • IEC 62040-2 Class A EMI
  • GOST
Software Included:
PowerAlert Monitoring Software
Environmentally Friendly:
Yes
Country of Origin:
China
Warranty
Limited Warranty:
2 Year
Item Numbers
GTIN: 0037332181381
UPC: 037332181381
EAN: 0037332181381
UNSPSC: 39121011
