Tripp-Lite OMNIVS1500XL Products

Tripp-Lite - Tripp Lite UPS 1500VA 940W Battery Back Up Tower AVR 120V RJ11 RJ45 - Tower - 4 Hour Recharge - 5 Minute Stand-by - 110 V AC Input - 120 V AC Output - 2 x NEMA 5-15R, 6 x NEMA 5-15R
  • 1500VA / 1.5kVA tower 120V line interactive extended-run UPS
  • Corrects brownouts and overvoltages from 75 to 147V
  • 6 UPS battery supported outlets, 2 surge-only outlets
  • USB port, TEL/DSL/ethernet protection, External battery pack options
  • NEMA 5-15P input plug and 8 NEMA 5-15R outlets
Read More

Need a different version? See all Tripp-Lite Parts Accessories

$415.94
In Stock
Chat Now for Qty Discount
Add to Quote
Add to My Shopping List Add to Compare
Tripp-Lite OMNIVS1500XL Products
Tripp-Lite OMNIVS1500XL Products
Tripp-Lite OMNIVS1500XL Products
Tripp-Lite OMNIVS1500XL Products Tripp-Lite OMNIVS1500XL Products Tripp-Lite OMNIVS1500XL Products
Tripp-Lite Parts Accessory Model Overview
Products and parts from Tripp-Lite.
Tripp-Lite OMNIVS1500XL Products Overview

Line Interactive UPS system with eight outlets offers voltage regulation, surge suppression and long-lasting, expandable battery support for personal computers, Internet-working equipment and other sensitive electronics. Internal UPS circuits support entry level PC systems for up to 75 minutes during power failures so that connected equipment can be shut down without data loss. Automatic Voltage Regulation circuits regulate brownouts as low as 75 and overvoltages up to 147 volts back to usable 120V levels without using battery power. Includes six battery supported outlets for computer, monitor and one vital system peripheral, plus two additional surge suppression-only outlets for printers and other system accessories not requiring battery support. Built-in dataline suppression offers protection for equipment with single-line telephone/DSL or network Ethernet connection. Offers 5 minute battery runtime with a full load of 1500VA and 14 minutes with a half load of 750VA.

Technical Information
Plug/Connector Type:
NEMA 5-15P
Receptacle Type:
NEMA 5-15R
Receptacle Detail:
  • 2 x NEMA 5-15R
  • 6 x NEMA 5-15R
Dataline Protection:
RJ-45
Cord Length:
6 ft
Transfer Time:
4 ms
Power Description
Load Capacity:
1500 VA/940 W
Input Voltage:
110 V AC
Output Voltage:
120 V AC
Surge Energy Rating:
480 J
Management
Alarm:
On Battery
Controls/Indicators
Status Indicators:
4 front panel LEDs indicate line power status, battery power status, battery low/replace status and voltage regulation operation
Interfaces/Ports
USB:
Yes
Battery Information
Backup/Run Time (Full Load):
5 Minute
Backup/Run Time (Half Load):
14 Minute
Battery Life:
6 Year
Typical Battery Recharge Time:
4 Hour
Hot Swappable:
Yes
Environmental Conditions
Maximum Operating Temperature:
122°F (50°C)
Physical Characteristics
Product Color:
Black
Height:
11.8"
Width:
7.3"
Depth:
7.5"
Form Factor:
Tower
Weight (Approximate):
32.20 lb
Miscellaneous
Package Contents:
  • OMNIVS1500XL Line Interactive UPS
  • USB and telephone cable
  • User manual with warranty information
Additional Information:
  • OMNIVS1500XL Uninterruptible Power Supply offers voltage regulation, surge suppression and long lasting battery support
  • Supports entry level PCs up to 75 minutes during blackouts to enable shutdown without data loss
  • Regulates brownouts as low as 75 and overvoltages to 147V back to usable 120V nominal levels without using battery power
  • 6 UPS battery supported outlets, plus 2 additional surge suppression-only outlets
  • USB port and cable enables UPS monitoring and unattended shutdown in the case of extended power failure
  • PowerAlert software available via free download from www.tripplite.com
  • Dataline surge suppression protects standard dialup/DSL or ethernet line connection
  • Audible alarm and 4 front panel LEDs offer complete UPS and line power status information
  • 1500VA power handling ability supports a variety of sensitive electronic equipment
  • 5 minutes full load runtime (1500VA), 14 minutes half load runtime (750VA)
  • Runtime is further expandable with the addition of BP24V14 external battery pack
  • Supports hot swappable battery replacement via built-in access panel
  • $200,000 connected equipment insurance (USA & Canada Only)
  • 2 year warranty
Certifications & Standards:
  • UL1778 (USA)
  • cUL (Canada)
  • FCC Class B (emissions)
  • NOM (Mexico)
  • FCC Part 68 / Industry Canada (telecommunications)
Recycled:
No
Assembly Required:
No
Country of Origin:
China
Warranty
Limited Warranty:
3 Year
Additional Warranty Information:

$200,000 connected equipment insurance (USA, Puerto Rico & Canada Only)

Item Numbers
GTIN: 0012300075046, 0037332119735, 0562698522658, 0818257819746
UPC: 012300075046, 037332119735, 562698522658, 818257819746
EAN: 0012300075046, 0037332119735, 0562698522658, 0818257819746
UNSPSC: 39121011
Get help from a Barcoding Expert!

What type of Barcode are you scanning?

The Tripp-Lite OMNIVS1500XL Products is also known as OMNIVS1500XL
