Tripp-Lite OMNI900LCD Products

Tripp-Lite  -  Tripp Lite UPS 900VA 475W Battery Back Up Tower LCD AVR 120V USB - 900VA/475W - 3 Minute Full Load - 4 x NEMA 5-15R - Battery/Surge-protected, 4 x NEMA 5-15R - Surge-protected

  • 900VA tower 120V line interactive UPS with LCD display
  • Corrects brownouts as low as 89V without using battery power
  • LCD screen reports input voltage, battery charge and UPS status
  • USB port, Surge-only outlets, 97% efficiency
  • NEMA 5-15P input plug and 8 NEMA 5-15R outlets
Read More
Need a different version? See all Tripp-Lite Parts Accessories

Price Match Guarantee

Found a better price? We'll match it within 30 days of your purchase.

Chat Now for Qty Discount
Add to Quote
Add to My Shopping List Add to Compare
$272.51
In Stock
Tripp-Lite OMNI900LCD Products
Tripp-Lite OMNI900LCD Products
Tripp-Lite OMNI900LCD Products
Tripp-Lite OMNI900LCD Products
Tripp-Lite OMNI900LCD Products Tripp-Lite OMNI900LCD Products Tripp-Lite OMNI900LCD Products Tripp-Lite OMNI900LCD Products

Tripp-Lite Parts Accessory Model Overview

Products and parts from Tripp-Lite.
Tripp-Lite OMNI900LCD Products Overview

Tripp Lite's OMNI900LCD Line-Interactive Digital UPS System offers voltage regulation, surge suppression and long lasting battery support for personal computers, home entertainment systems and media centers. Internal UPS circuits support entry level PCs for up to 50 minutes or individual VCR/DVR components for as long as 2.5 hours during power failures. Prevents data loss, viewing interruptions, lost recordings and loss of component programming. Automatic Voltage Regulation (AVR) circuits regulate brownouts as low as 89 volts back to usable levels without using battery power. 97% line-mode efficiency saves energy and reduces BTU heat output. Offers complete power protection in an attractive black tower configuration. Includes 4 battery-supported and surge-protected outlets, plus 4 additional surge suppression-only outlets for items not requiring battery support. USB port enables optional unattended system shutdown without data loss in the case of extended power failure. PowerAlert software available via free download from www.tripplite.com. HID-compliant USB interface enables integration with built-in power management and auto shutdown features of Windows and Mac OS X. Built-in audible alarm and large LCD front panel voltage display indicates line power status, battery power status, battery low/replace status and voltage boost operation. The LCD display includes a dimmer switch and can be rotated for easy viewing in any application. 900VA/475 watt power handling ability supports entry-level PCs, home entertainment systems, network workstations, audio/video components. Offers 3 minutes battery runtime with a full load of 900VA/475 watts and 10 minutes with a half load of 450VA/237 watts. Supports battery replacement via built-in access panel. $200,000 Ultimate Lifetime Insurance (U.S., Canada, and Puerto Rico only).

Technical Information
Plug/Connector Type:
NEMA 5-15P
Receptacle Type:
NEMA 5-15R
Receptacle Detail:
8 x NEMA 5-15R
Transfer Time:
3 ms
Power Description
Load Capacity:
900 VA/475 W
Input Voltage:
110 V AC
Output Voltage:
120 V AC
Input Current:
12 A
Waveform Type:
Pulse-width Modulated Sine Wave
Surge Energy Rating:
870 J
Management
Alarm:
AC Input Failure
Controls/Indicators
Status Indicators:

Front panel LCD screen with blue backlight offers:

  • Continuous input line voltage data
  • UPS status information on line power status
  • Battery power status
  • Battery charge level
  • Voltage regulation operation
Interfaces/Ports
USB:
Yes
Battery Information
Backup/Run Time (Full Load):
3 Minute
Backup/Run Time (Half Load):
10 Minute
Battery Life:
6 Year
Typical Battery Recharge Time:
20 Hour
Hot Swappable:
Yes
Environmental Conditions
Maximum Operating Temperature:
122°F (50°C)
Physical Characteristics
Product Color:
Black
Height:
11.8"
Width:
3.7"
Depth:
7.2"
Form Factor:
Tower
Weight (Approximate):
14.90 lb
Miscellaneous
Package Contents:
  • OmniSmart OMNI900LCD 900 VA Tower UPS
  • Manual with Warranty Information
Additional Information:
  • Low voltage transfer to battery power: Switches to battery power as line voltage decreases to 89V or less, switches back to AC mode as line voltage increases to 94V or higher
  • High voltage transfer to battery power: Switches to battery mode as line voltage increases to 139V or higher, switches back to AC mode as line voltage decreases to 135V or lower
  • Network monitoring port: Single built-in USB port supports on battery, low battery and power restored messaging. Interface supports timed inverter shutoff after unattended shutdown. Compatible with Tripp Lite's PowerAlert and Watchdog service software
  • Compatible with Tripp Lite's Watchdog system service to restore operation to locked equipment through soft reboot of application / OS or hard power off/on reboot of connected equipment ideal for unattended kiosk applications
  • Switches: Includes 2 front panel switches - one main on/off power switch and one dual function "alarm cancel" / "self test" button
  • Entry-level PCs, networked workstations, point-of-sale equipment, small business phone systems, audio/video equipment and home theater systems. Ideal for sensitive electronic applications in areas where brownout conditions are common
Certifications & Standards:
  • UL1778 (TUV)
  • cUL (TUV)
  • NOM
  • FCC Class B
Software Included:
PowerAlert software
Environmentally Friendly:
Yes
Country of Origin:
China
Warranty
Limited Warranty:
3 Year
Item Numbers
GTIN: 0037332125156, 0373321251568, 0996589537078, 4923213146722
UPC: 037332125156, 373321251568, 996589537078
EAN: 0037332125156, 0373321251568, 0996589537078, 4923213146722
UNSPSC: 39121011
