Tripp-Lite NG24 Data Networking

Tripp-Lite - Tripp Lite 24-Port Gigabit Ethernet Switch Rackmount Unmanaged Metal 1U - 24 Ports - 2 x Expansion Slots - 1000Base-T, 1000Base-X - Modular - 24 x Network, 2 x Expansion Slot - Twisted Pair, Optical Fiber - Gigabit Ethernet - Shared SFP Slot - 2 x SFP Slots - 2 Layer Supported - 1U High - Desktop, Rack-mountable - 5 Year
  • 24 auto-negotiable 10/100/1000 Mbps RJ45 ports
  • Dual mini-GBIC SFP ports
  • Supports auto MDI/MDIX cross-over function
  • Consumes very little input power-just 20W max
  • 2 Gbps switching capacity per port with full duplex
Read More
$193.54
In Stock
Recommended TrueSupport Coverage (/mo.)

x

Are you sure you don't need TrueSupport?

The average internal IT
cost for device support is over per year!

With TrueSupport you're
covered - and for way less!
  • Hardware Helpdesk Support
  • RMA Repair Facilitation
  • OEM Service Contract Management
  • Premium Phone & Email Support
  • Billed annually per device

Only /month
Subtotal ( items)

x
You've just added this product to the cart:

Go To Cart
Add to Quote
Tripp-Lite Parts Accessory Model Overview
Products and parts from Tripp-Lite.
Tripp-Lite NG24 Data Networking Overview

The NG24 24-Port 10/100/1000 Mbps 1U Rack-Mount/Desktop Gigabit Ethernet Unmanaged Switch adds 10/100/1000 Mbps Ethernet capacity to your home office, small office, workgroup or creative production environment. Share large bandwidth-intensive files, such as CAD drawings and videos, at Gigabit speeds, improving efficiency and cutting costly downtime.

This rack-mount/ desktop switch features 24 twisted-pair RJ45 Gigabit Ethernet ports that support auto-negotiable 10/100/1000 Mbps and auto MDI/MDIX cross-over detection functions. Dual mini-GBIC SFP ports allow connection to other switches using optical fiber or copper. No configuration is required, so you can have your Gigabit network up and running immediately. Easy-to-read LEDs indicate connection and activity status for each port. IEEE 802.3x flow control allows smooth transmission of large files.

The NG24 supports IEEE 802.3az Energy Efficient Ethernet standards by putting unused ports into a low-power state without interrupting network connections. It consumes very little input power-just 20 watts max. The detachable five-foot input cord with NEMA 5-15P plug connects to a protected UPS, generator or mains input AC source. The heavy-duty metal housing is designed for desktop installation or mounting into 1U of an EIA-standard 19-inch rack with the included brackets.

Interfaces/Ports
Total Number of Network Ports:
24
Uplink Port:
No
Modular:
Yes
Stack Port:
No
Port/Expansion Slot Details:
  • 24 x Gigabit Ethernet Network
  • 2 x Gigabit Ethernet Expansion Slot
Media & Performance
Media Type Supported:
  • Twisted Pair
  • Optical Fiber
Ethernet Technology:
Gigabit Ethernet
Network Technology:
10/100/1000Base-T
I/O Expansions
Number of Total Expansion Slots:
2
Expansion Slot Type:
SFP (mini-GBIC)
Shared SFP Slot:
Yes
Number of SFP Slots:
2
Network & Communication
Layer Supported:
2
Management & Protocols
Manageable:
No
Power Description
Power Source:
Power Supply
Redundant Power Supply Supported:
No
Physical Characteristics
Compatible Rack Unit:
1U
Form Factor:
  • Desktop
  • Rack-mountable
Height:
1.7"
Width:
17.3"
Depth:
8.1"
Weight (Approximate):
5.40 lb
Miscellaneous
Package Contents:
  • NG24 Ethernet Switch
  • Detachable AC power cord with NEMA 5-15P plug, 5 ft.
  • 2 x Mounting brackets
  • 8 x Screws
  • 4 x Rubber feet
  • Owner's manual
Environmentally Friendly:
Yes
Environmental Certification:
RoHS
Country of Origin:
China
Warranty
Limited Warranty:
5 Year
Item Numbers
GTIN: 0037332194732, 0818240218631
UPC: 037332194732, 818240218631
EAN: 0037332194732, 0818240218631
UNSPSC: 43222612
Get help from a Barcoding Expert!

What type of Barcode are you scanning?

The Tripp-Lite NG24 Data Networking is also known as NG24
