Tripp-Lite B156-002-HDMI Accessory

Tripp-Lite - Tripp Lite 2-Port Video Displayport to 2 X HDMI Monitor Video Splitter 4Kx2K @ 24/30Hz TAA GSA - DisplayPort - HDMI Out - TAA Compliant
  • Compliant with DisplayPort 1.2
  • Splits or expands a DisplayPort audio/video signal on two HDMI monitors
  • Display the same image on each monitor, extend the desktop across them, or display in video wall mode where monitors are combined to display as one
  • Supports 4K x 2K Ultra High Definition (UHD) video resolutions up to 3840 x 2160 (24 and 30 Hz) - see System Requirements
  • Supports up to 48-bit Deep Color (16 bits per channel)
  • Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases
Read More

Need a different version? See all Tripp-Lite Parts Accessories

$110.34
In Stock
Chat Now for Qty Discount
Add to Quote
Add to My Shopping List Add to Compare
Tripp-Lite B156-002-HDMI Accessory
Tripp-Lite B156-002-HDMI Accessory
Tripp-Lite B156-002-HDMI Accessory
Tripp-Lite B156-002-HDMI Accessory Tripp-Lite B156-002-HDMI Accessory Tripp-Lite B156-002-HDMI Accessory
Tripp-Lite Parts Accessory Model Overview
Products and parts from Tripp-Lite.
Tripp-Lite B156-002-HDMI Accessory Overview

Get everyone's attention by broadcasting awesome messages in ultra-high definition video! With Tripp Lite's B156-002-HDMI 2-Port DisplayPort 1.2 to HDMI MST Hub, you can split or expand a single DisplayPort signal into two separate signals and display them on two HDMI monitors using standard DisplayPort (Tripp Lite P580-Series or P583-Series) and HDMI (Tripp Lite P568-Series) cables. You can display the same image on each monitor, extend the desktop across them, or display in video wall mode where monitors are combined to display as one, enlarged monitor. The B156-002-HDMI supports 4Kx2K Ultra-High Definition (UHD) video resolutions up to 3840 x 2160 (30 Hz), 48-bit Deep Color (16 bits per channel), and is compatible with HDCP, EDID and DDC. It comes with an external power supply and brackets for wall-, rack- or pole-mounting. All mounting hardware is included. Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases.

Interfaces/Ports
DisplayPort:
Yes
HDMI Out:
Yes
Number of DisplayPort Inputs:
1
Number of HDMI Outputs:
2
Physical Characteristics
Weight (Approximate):
1 lb
Miscellaneous
Package Contents:
  • Displayport to 2 X HDMI Splitter - 2 Port
  • Mounting Hardware
  • External Power Supply (Input: 100-240V, 50/60Hz, 0.5A; Output: 5V, 2A)
Additional Information:
  • Supports both 4Kx2K (3840 x 2160 at 24 or 30Hz) UHD video and standard 1080p (1920x1080 at 60Hz) high-definition video
  • Supports up to 48-bit Deep Color (16 bits per channel) and video resolutions up to 4K Ultra High Definition (UHD), 3840 x 2160 @ 24 or 30Hz
  • Complies with HDCP, EDID and DDC
  • Compatible with DisplayPort 1.2
  • Compatible with Apple® Thunderbolt connectors
  • Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases
Environmentally Friendly:
Yes
Environmental Certification:
RoHS
Country of Origin:
Taiwan
TAA Compliant:
Yes
Warranty
Limited Warranty:
3 Year
Item Numbers
GTIN: 0037332175892, 0102930764417, 0803931109398, 7427457767783
UPC: 037332175892, 102930764417, 803931109398
EAN: 0037332175892, 0102930764417, 0803931109398, 7427457767783
UNSPSC: 32101529
Get help from a Barcoding Expert!

What type of Barcode are you scanning?

The Tripp-Lite B156-002-HDMI Accessory is also known as B156002HDMI
