Tripp-Lite B118-004-UHD-2 Accessory

Tripp-Lite - Tripp Lite 4-Port 3D HDMI Splitter HDCP 2.2, HDR, 4K @ 60Hz Ultra HD Video Audio - 3840 +160 - 22.97 ft Maximum Operating Distance - HDMI In - HDMI Out - Metal - TAA Compliant
  • Transmits Ultra High Definition (UHD) 4K x 2K audio/video (A/V) from an HDMI source to four HDMI displays at the same time.
  • Recommended for digital signage in classrooms, churches, office buildings, restaurants/bars, etc.
  • Transmits UHD video resolutions up to 4K x 2K @ 60 Hz
  • Distributes A/V up to 15 ft. when used with 28 AWG HDMI cable
  • Supports DTS-HD, Dolby® TrueHD and Dolby Digital Plus™
  • Compatible with HDCP 2.2, 3D, EDID and HDMI 2.0
  • Supports High Dynamic Range (HDR) for richer contrast and expanded color accuracy
  • Expand the number of connected displays, up to 64, by cascading up to 3 levels of splitters together
  • Plug and play-no software or drivers required
  • 3-year limited warranty
Read More

Need a different version? See all Tripp-Lite Parts Accessories

$147.95
Chat Now for Qty Discount
Add to Quote
Add to My Shopping List Add to Compare
Tripp-Lite B118-004-UHD-2 Accessory
Tripp-Lite B118-004-UHD-2 Accessory
Tripp-Lite B118-004-UHD-2 Accessory Tripp-Lite B118-004-UHD-2 Accessory
Tripp-Lite Parts Accessory Model Overview
Products and parts from Tripp-Lite.
Tripp-Lite B118-004-UHD-2 Accessory Overview

4-Port HDMI splitter transmits Ultra High Definition (UHD) 4K x 2K audio/video (A/V) from an HDMI source to four HDMI displays at the same time. Plug-and-play technology makes installation quick and simple - with no software or drivers to install. Using standard 28 AWG HDMI cabling, this splitter can transmit full 3D and a 4K x 2K (3840 x 2160) signal up to 15'. It supports a wide range of audio formats, including DTS-HD, Dolby TrueHD, Dolby Digital Plus, and LPCM 7.1-channel surround sound as well as 36-bit Deep Color (12 bits per channel). Splitter also supports HDMI 2.0 and HDCP 2.2 to ensure its compatibility with the latest audio/video hardware.

Video
Maximum Video Resolution:
3840 × 2160
Interfaces/Ports
HDMI In:
Yes
HDMI Out:
Yes
Number of HDMI Inputs:
1
Number of HDMI Outputs:
4
Media & Performance
Maximum Operating Distance:
22.97 ft
Power Description
Input Voltage:
  • 120 V AC
  • 230 V AC
  • 5 V DC
Physical Characteristics
Product Material:
Metal
Miscellaneous
Package Contents:
  • B118-004-UHD-2 4-Port 4K 3D HDMI Splitter
  • External Power Supply (Input: 100-240V, 50/60 Hz, 0.35A; Output: 5V 2A)
  • International Plug Adapters (North America, Europe, U.K. and Australia)
  • Mounting Hardware
  • Owner's Manual
Environmental Certification:
RoHS
Country of Origin:
Taiwan
TAA Compliant:
Yes
Warranty
Limited Warranty:
3 Year
Item Numbers
GTIN: 0037332200655, 0818241643418, 0993242611472
UPC: 037332200655, 818241643418, 993242611472
EAN: 0037332200655, 0818241643418, 0993242611472
UNSPSC: 32101529
