Tripp-Lite B030-DP16-17D Ethernet Switch

Part Number: B030-DP16-17D
Model: Parts
to get Free Ground Shipping on your order.
$5,086.62

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
KVM Switch
Yes
Number of Computers Supported
16
Device Type
LCD Rack Console
Screen Size
17"

Product Description:

  Tripp Lite DisplayPort KVM Console Switch 16-Port 17in LCD Dual Rail 1URM, 16 Computer(s), 17" LCD, Full HD, 1920 x 1080, 16:9, 18 x USB, Keyboard, TouchPad, 1U High, PC, Mac, Unix, Linux, Metal, Black, TAA Compliant

Tripp-Lite Parts Accessory Model Overview

Products and parts from Tripp-Lite.
Tripp-Lite B030-DP16-17D Ethernet Switch Overview

Connects 16 DisplayPort Computers or Servers to a Single Monitor, Keyboard and Mouse
This NetDirector® DisplayPort KVM switch combines a rack-mountable keyboard, 17-inch LCD, touchpad and 16 DisplayPort inputs into a compact housing that occupies only 1U of rack space. Access, control, boot and reboot up to 16 DisplayPort computers or servers at the same time. No adapters are needed for connecting DisplayPort-enabled equipment.

Saves Valuable Space and Keeps Your Operating Costs Low
All connected DisplayPort computers or servers share a single monitor, keyboard and mouse, which saves space in your rack or workspace. DDC emulation allows each computer's settings to adjust automatically for optimal screen output. Eliminating the cost of buying monitors, adapters, keyboards and mice for all 16 connected devices keeps your TCO (total cost of ownership) low.

17 in. LCD Supports Crystal-Clear 1080p Video
The dual-rail B030-DP16-17D supports high-definition video resolutions up to 1920 x 1080 (1080p) at 60 Hz. The wide display flips up to provide access to connected computers, making multitasking easier and more convenient, and folds down to prevent the console from blocking adjacent rack equipment when not in use. The LCD and the keyboard/touchpad are on separate rails, so the LCD can remain open while the keyboard/touchpad is stored out of the way, keeping the rack aisle clear.

Switching Between Computers Is Fast and Easy
Use the on-console push buttons, keyboard hotkey commands or multi-lingual local console On-Screen Display (OSD) to quickly toggle between connected computers. You can also use the Auto Scan feature to scan all connected computers in five-second intervals automatically. Orange LEDs indicate which computer is currently selected. Computers or servers can be quickly added or removed without having to power down the KVM switch.

Multi-Level Password Security Keeps Your Private Data Private
Security is enhanced by limiting access to one administrator and no more than four local users. Two-level logout procedure allows you to log out manually or log out automatically after a user-defined period of time has passed.

Long-Lasting Reliability and Compatibility
This DisplayPort KVM switch mounts easily into 1U of space in an EIA-standard 19-inch rack with the included brackets (Tripp Lite's optional B019-000 - sold separately - allows mounting in a 2-post rack). The B030-DP16-17D is compatible with all major operating systems, including Windows and macOS, for simple integration into your existing structure. Mac/Sun keyboard emulation also is supported. The RJ11 port allows you to upgrade the KVM switch's firmware using the included cable.

TAA-Compliant for GSA Schedule Purchases
The B030-DP16-17D is compliant with the Federal Trade Agreements Act (TAA), which makes it eligible for GSA (General Services Administration) Schedule and other federal procurement contracts.

Typical Applications

Access and control up to 16 computers and servers with DisplayPort video ports

System Requirements

  • Resolution settings of all connected displays must not exceed 1920 x 1080 @ 60 Hz
  • DisplayPort graphics card
  • USB keyboard/mouse ports
  • Windows, macOS, Linux, UNIX or Novell operating system
  • DisplayPort monitor and USB keyboard/mouse (optional external console)
Technical Information
KVM Switch:
Yes
Number of Computers Supported:
16
Device Type:
LCD Rack Console
Display & Graphics
Screen Size:
17"
Display Screen Type:
LCD
Screen Mode:
Full HD
Screen Resolution:
1920 x 1080
Aspect Ratio:
16:9
Input Devices
Keyboard:
Yes
Pointing Device Type:
TouchPad
Interfaces/Ports
USB:
Yes
DisplayPort:
Yes
Number of USB Ports:
18
Physical Characteristics
Product Color:
Black
Product Material:
Metal
Height:
1.7"
Width:
18.9"
Depth:
26.8"
Weight (Approximate):
31 lb
Miscellaneous
Package Contents:
  • B030-DP16-17D 16-Port DisplayPort KVM Switch Console
  • 2 x DisplayPort cables, 6 ft.
  • 2 x USB 2.0 A/B cables, 6 ft.
  • RJ11 firmware upgrade cable
  • C13 to NEMA 5-15P power cord
  • Grounding Wire
  • CD with Owner's Manual
  • Quick Start Guide
Platform Supported:
  • PC
  • Mac
  • Unix
  • Linux
Environmentally Friendly:
Yes
Environmental Certification:
  • RoHS
  • REACH
Country of Origin:
Taiwan
TAA Compliant:
Yes
Warranty
Limited Warranty:
1 Year
Item Numbers
GTIN: 0037332258731
UPC: 037332258731
EAN: 0037332258731
UNSPSC: 43222634
