Tripp-Lite AVR750U Accessory

Part Number: AVR750U
Model: UPS
$178.17
In Stock

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
AVR
Yes
AVR Range
Boost +18% / Buck -15%
Plug/Connector Type
NEMA 5-15P
Receptacle Type
NEMA 5-15R

Product Description:

  Tripp Lite UPS 750VA 450W Desktop Battery Back Up AVR 50/60Hz Compact 120V USB RJ11 - Desktop - 12 Hour Recharge - 3 Minute Stand-by - 120 V AC Input - 110 V AC, 115 V AC, 120 V AC Output - 12 x NEMA 5-15R

Tripp-Lite UPS Accessory Model Overview

Tripp-Lite UPS and Power Supply products.
Tripp-Lite AVR750U Accessory Overview
AVR Series Line-Interactive UPS System offers ultra-compact, line-interactive protection for PCs and workstations. System maintains 120 volt nominal output over an input range of 83 to 147 volts. Workstation-optimized features include USB port (HID-PDC compliant), single-line telephone/DSL surge suppression, space saving right-angle input plug, six battery/surge-protected outlets and six additional surge-only outlets (12 total). USB port (included cable) works with free unattended shutdown software. Housing is mountable.

More from the Manufacturer

Technical Information
AVR:
Yes
AVR Range:
Boost +18% / Buck -15%
Plug/Connector Type:
NEMA 5-15P
Receptacle Type:
NEMA 5-15R
Receptacle Detail:
12 x NEMA 5-15R
Number of Battery & Surge Outlets:
6
Number of Surge-only Outlets:
6
Dataline Protection:
RJ-11
Transfer Time:
6 ms
EMI/RFI Noise Filter:
Yes
Phase:
Single Phase
Energy Saving:
Greater than 95% efficiency - GREEN UPS
Application/Usage:
  • Computer
  • Router
  • Printer
  • TV
  • Blu-ray Player
  • Gaming Console
  • ATM
  • Security System
  • Digital Signage
  • Home/Office
  • Media Center
  • Home Theater
Power Description
Load Capacity (VA):
750 VA
Load Capacity (Watt):
450 W
Input Voltage:
120 V AC
Input Current:
12 A
Output Voltage:
  • 110 V AC
  • 115 V AC
  • 120 V AC
Input Frequency:
60 Hz
Output Frequency:
60 Hz
Waveform Type:
Pulse-width Modulated Sine Wave
Surge Energy Rating:
316 J
Management
Alarm:
  • Battery Backup
  • Low Battery
  • Overload
  • Replace Battery
  • Fault
Controls/Indicators
Status Indicators:

2 Status LEDs; GREEN indicates power status and operating mode / RED indicates battery-low, overload, replace-battery and fault conditions

Interfaces/Ports
USB:
Yes
USB (HID Compliant) Port:
Yes
Battery Information
DC System Voltage:
12 V DC
Backup/Run Time (Full Load):
3 Minute
Backup/Run Time (Half Load):
11 Minute
Typical Battery Recharge Time:
9 Hour
Replaceable Battery:
Yes
Environmental Conditions
Maximum Operating Temperature:
104°F (40°C)
Storage Temperature:
5°F (-15°C) - 113°F (45°C)
Maximum Operating Elevation:
10000 ft
Physical Characteristics
Color Family:
Black
Product Color:
Black
Height:
4.1"
Width:
7.5"
Depth:
12"
Form Factor:
Ultra-compact Desktop/Tower/Wall Mount
Weight (Approximate):
15.84 lb
Miscellaneous
Package Contents:
  • AVR 750VA Desktop UPS
  • USB cable
  • Instruction manual
Certifications & Standards:

Energy Star

Recycled:
No
Assembly Required:
No
Country of Origin:
Vietnam
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
Warranty
Limited Warranty:
3 Year Lifetime
Additional Warranty Information:

2-year warranty. $100,000 Ultimate Lifetime Insurance (USA, Puerto Rico and Canada only).

Item Numbers
GTIN: 0013297544881, 0037332123121, 0037332211484, 0635665341078, 0666673804774, 0993244971093
UPC: 013297544881, 037332123121, 037332211484, 635665341078, 666673804774, 993244971093
EAN: 0013297544881, 0037332123121, 0037332211484, 0635665341078, 0666673804774, 0993244971093
UNSPSC: 39121011
