Tripp-Lite AVR550U Products

Tripp-Lite - Tripp Lite UPS 550VA 300W Desktop Battery Back Up AVR Compact 120V USB RJ11 50/60Hz - Mini Desktop - 9 Hour Recharge - 2 Minute Stand-by - 110 V AC Input - 120 V AC Output - 8 x NEMA 5-15R
  • Protects equipment against blackouts, brownouts, overvoltages, surges and line noise
  • Keeps AC power running during blackouts to allow time for file saves and safe shutdown
  • 8 NEMA 5-15R outlets power and protect PC, home theater or digital signage equipment
  • Home-friendly alarm remains silent in backup mode, sounding only when imperative
  • High >95% efficiency with low BTU ratings saves electricity and lowers your energy costs
  • 3-year limited warranty
  • $100,000 Ultimate Lifetime Insurance
Read More

Need a different version? See all Tripp-Lite Parts Accessories

$122.43
In Stock
Add to Quote
Add to My Shopping List Add to Compare
Tripp-Lite AVR550U Products
Tripp-Lite AVR550U Products Tripp-Lite AVR550U Products Tripp-Lite AVR550U Products Tripp-Lite AVR550U Products
Tripp-Lite AVR550U Products
Tripp-Lite AVR550U Products
Tripp-Lite AVR550U Products
Tripp-Lite AVR550U Products
Tripp-Lite Parts Accessory Model Overview
Products and parts from Tripp-Lite.
Tripp-Lite AVR550U Products Overview
AVR Series Line-Interactive UPS System offers 550VA ultra-compact line-interactive protection for PCs and workstations. System maintains 120 volt nominal output over an input range of 83 to 147 volts. Workstation-optimized features include USB port (HID-PDC compliant), single-line telephone/DSL surge suppression, space-saving right-angle input plug, four battery/surge-protected outlets and four additional surge-only outlets (8 total). USB port (included cable) works with free unattended shutdown software. Housing is mountable.

More from the Manufacturer

Technical Information
AVR:
Yes
AVR Range:
Boost +18% / Buck -15%
Plug/Connector Type:
NEMA 5-15P
Receptacle Type:
NEMA 5-15R
Receptacle Detail:
8 x NEMA 5-15R
Number of Battery & Surge Outlets:
4
Number of Surge-only Outlets:
4
Dataline Protection:
RJ-11
Cord Length:
6 ft
Transfer Time:
6 ms
EMI/RFI Noise Filter:
Yes
Phase:
Single Phase
Energy Saving:
Greater than 95% efficiency - GREEN UPS
Application/Usage:
  • Printer
  • Speaker
  • Computer
  • Router
  • TV
  • Blu-ray Player
  • Gaming Console
  • ATM
  • Security System
  • Digital Signage
  • Media Center
  • Home/Office
  • Home Theater
Power Description
Load Capacity:
550 VA/300 W
Input Voltage:
120 V AC
Output Voltage:
  • 110 V AC
  • 115 V AC
  • 120 V AC
Input Current:
12 A
Input Frequency:
60 Hz
Output Frequency:
60 Hz
Waveform Type:
Pulse-width Modulated Sine Wave
Surge Energy Rating:
316 J
Management
Alarm:
  • Battery Backup
  • Low Battery
  • Overload
  • Replace Battery
  • Fault
Controls/Indicators
Status Indicators:

2 Status LEDs; GREEN indicates power status and operating mode / RED indicates battery-low, overload, replace-battery and fault conditions

Interfaces/Ports
USB:
Yes
USB (HID Compliant) Port:
Yes
Battery Information
DC System Voltage:
12 V DC
Backup/Run Time (Full Load):
2 Minute
Backup/Run Time (Half Load):
9 Minute
Battery Life:
6 Year
Typical Battery Recharge Time:
8 Hour
Replaceable Battery:
Yes
Environmental Conditions
Maximum Operating Temperature:
104°F (40°C)
Storage Temperature:
5°F (-15°C) - 113°F (45°C)
Maximum Operating Elevation:
10000 ft
Physical Characteristics
Product Color:
Black
Height:
4.3"
Width:
6.4"
Depth:
12"
Form Factor:
Ultra-compact Desktop/Tower/Wall Mount
Weight (Approximate):
13.69 lb
Miscellaneous
Package Contents:
  • Desktop/Wall Mount Battery Backup Outlets
  • USB cable
  • Owner's manual
Additional Information:
  • Low voltage transfer to battery power: Switches to battery power as line voltage drops to 83V or lower / Resets to AC mode as line voltage increases to 87V or higher
  • High voltage transfer to battery power: Switches to battery power as line voltage increases to 147V or higher / Resets to line power as line voltage drops to 143V or less
  • Cold Start: Yes, inverter can be "cold started" to enable temporary AC output during a power failure
  • Switches: Combination power off / on / self-test push button switch
  • Typical Application: Basic PCs for home / home-office use, network workstations, audio/video equipment, home entertainment systems and other sensitive electronic devices.
  • WatchDog compatibility: Yes, compatible with Tripp Lite's Watchdog system service to restore operation to locked equipment through soft reboot of application / OS or hard power off/on reboot of connected equipment - ideal for unattended kiosk applications
  • Supports entry-level PC systems up to 17 minutes during blackout conditions
  • Form factors supported: Ultra-compact desk/floor mount , mounting flanges enable wall-mount installation
  • 8 output receptacles, 2 of which are widely spaced to accommodate large transformer plugs without blocking outlets
  • 4 outlets feature full battery support and surge suppression, protecting computers, monitors and other vital system components from loss of power
  • 4 additional outlets with surge suppression only are ideal for printers and other peripherals not requiring battery support
  • HID-compliant USB interface enables full integration with built-in power management and auto shutdown features of Windows, Mac OS X and Linux
Certifications & Standards:
  • Tested to UL1778 (USA)
  • cUL1778 (Canada)
  • NOM (Mexico)
  • FCC Class B (Emissions)
  • FCC Part 68
  • Industry Canada (Telecommunications)
Software Included:
PowerAlert UPS monitoring software
Recycled:
No
Assembly Required:
No
Country of Origin:
Vietnam
Warranty
Limited Warranty:
3 Year Lifetime
Additional Warranty Information:

2-year warranty. $100,000 Ultimate Lifetime Insurance (USA, Puerto Rico and Canada only).

Item Numbers
GTIN: 0003733212344, 0010343812246, 0013297551117, 0037332123442, 0037332211453, 0635665338795, 0706919705509, 0742309939109, 0777785490721, 0801096833493, 0803931089478, 0803982804600, 0997852203317, 4923213145916
UPC: 003733212344, 010343812246, 013297551117, 037332123442, 037332211453, 635665338795, 706919705509, 742309939109, 777785490721, 801096833493, 803931089478, 803982804600, 997852203317
EAN: 0003733212344, 0010343812246, 0013297551117, 0037332123442, 0037332211453, 0635665338795, 0706919705509, 0742309939109, 0777785490721, 0801096833493, 0803931089478, 0803982804600, 0997852203317, 4923213145916
UNSPSC: 39121011
Get help from a Barcoding Expert!

What type of Barcode are you scanning?

The Tripp-Lite AVR550U Products is also known as DHD-AVR550U or AVR550U.
