TP-Link TL-POE10R PoE Injectors

Part Number: TL-POE10R
Model: Parts
to get Free Ground Shipping on your order.
Add to My Shopping List Add to Compare
$19.74

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Minimum Output Voltage
9 V DC
Maximum Output Voltage
12 V DC
Maximum Output Current
2 A
Input Ports
1 x 10/100Base-TX

Product Description:

  Cables, Connectors, and Adapters, Tp Link TP-LINK TL-POE10R Gigabit PoE Splitter Adapter, IEEE 802.3af compliant, Up to 100 meters (328 Feet), 5V/12V Power Output, 12 V DC, 15 V DC Output"
Explore all TP-Link Parts Security Cameras
Add to Quote
TP-Link TL-POE10R PoE Injectors
TP-Link TL-POE10R PoE Injectors

TP-Link Parts Security Camera Model Overview

Parts and products from TP-Link.
TP-Link TL-POE10R PoE Injectors Overview

The PoE Splitter TL-POE10R fully complies with IEEE 802.3af standard, and can work with all IEEE 802.3af PoE compliant PSE (Power Source Equipment) or PoE Supplier Adapter, such as TP-LINK's T1600G-52PS, TL-SG1008PE or TL-POE150S, or other equivalent product, to deliver 12V, 9V or 5V Direct Current to where there are no power line or outlet, where you wish to fix device such as AP, IP Camera or IP Phone, etc.

Power Description
Minimum Output Voltage:
9 V DC
Maximum Output Voltage:
12 V DC
Maximum Output Current:
2 A
Interfaces/Ports
Input Ports:
1 x 10/100Base-TX
Output Ports:
1 x 10/100Base-TX
Physical Characteristics
Height:
0.9"
Width:
3.2"
Depth:
2.1"
Miscellaneous
Package Contents:
  • TL-POE10R Power over Ethernet Splitter
  • Power Cord
  • RJ45 Cable
  • Installation Guide
Additional Information:
  • Compatible with IEEE 802.3af compliant power sources (PSE)
  • Delivers power up to 100 meters
  • Selectable 12VDC, 9VDC or 5VDC power output
  • Operating Temperature: 0?~40? (32?~104?)
  • Storage Temperature: -40?~70? (-40?~158?)
  • Operating Humidity: 10%~90% non-condensing
  • Storage Humidity: 5%~90% non-condensing
Compatibility:
  • IP Cameras
  • IP Phones
  • TP-LINK TL-SF1008P Desktop PoE Switch
  • TP-LINK TL-WA601G 108M Wireless Access Point
  • TP-LINK TL-SF1008D 10/100M Desktop Switch
Certifications & Standards:
FCC
Environmentally Friendly:
Yes
Item Numbers
GTIN: 0013044102197, 0818242437801, 0845973030490, 6935364030490
UPC: 013044102197, 657379374135, 818242437801, 845973030490
EAN: 0013044102197, 0818242437801, 0845973030490, 6935364030490
UNSPSC: 39121006
