Symbol M2004-I500 Barcode Scanner

Symbol M2004-I500R Barcode Scanner A newer version of this item is available.
It is replaced by the Symbol M2004-I500R Barcode Scanner.
Symbol M2004 Cyclone - scanner with RS232 & Synapse interfaces. Includes product reference guide. Order cables & power supply separately. See accessories. Color: black.
  • Perfect for applications that require direct association with a workstation or a notebook
  • Rapidly incorporate 1D and 2D barcode information to records, spreadsheets, and databases
  • Laser scan engine guarantees rapid error free data entry
Read More
Discontinued See Replacement
Add to Quote
Symbol M2004 Cyclone Barcode Scanner Model Overview
A smart investment, Symbol's innovative scanner is future-ready now. The M2004 Cyclone scanner decodes existing, new and emerging barcode symbologies instantly. The Cyclone scanner is packed with features that deliver optimum flexibility including next generation scanning technology. As good looking as it is practical, the Cyclone's sleek design complements any store's decor. Large merchandise or small, single or multiple barcode types, this scanner can handle it all. Revolutionary user-selectable scan pattern versatility plus remarkable ease of use and adaptability make the Adaptive "Cyclone" Scanner Series from Symbol Technologies a standout for barcode scanning at point of sale. All units ship with one product reference guide.
Symbol M2004-I500 Barcode Scanner Overview

A smart investment, Symbol's innovative new scanner is future-ready now. The Cyclone M2004 Bar Code Reader decodes existing, new and emerging bar code symbologies instantly. The Cyclone M2004 Bar Code Reader is packed with features that deliver optimum flexibility including next generation scanning technology. As good looking as it is practical, it's sleek design complements any store's decor. Large merchandise or small, single or multiple bar code types, this scanner can handle it all. Revolutionary user-selectable scan pattern versatility plus remarkable ease of use and adaptability make the Adaptive "Cyclone M2004 Bar Code Reader" from Symbol Technologies a standout for bar code scanning at point of sale.

Technical Information
Connectivity Technology:
Cable
Scanning Capability:
  • 1D
  • 2D
Barcode Symbology Supported:
  • UPC/EAN/JAN
  • NW7
  • Code 128
  • Code 39 Full ASCII
  • MSI/PLESSEY
  • Interleaved 2 of 5
  • Discrete 2 of 5
  • UCC/EAN
  • Codabar
  • PDF 417
  • RSS
Light Source:
Laser
Maximum Scan Resolution:
6.60 mil
Depth of Field:
  • 0" - 2"@6mil - Code 39 (Omni Zone)
  • 0" - 5.3"@80% UPC (Omni Zone)
  • 0.3" - 11"@100% UPC (Omni Zone)
  • 0.5" - 12"@20mil - Code 39 (Omni Zone)
  • 0" - 4"@6.6mil - PDF417
  • 2.25" - 6.5"@10mil - PDF417
  • 2.5" - 6.75"@10mil - PDF417
  • LC 35% (Raster Zone)
  • 5" - 8.5"@15mil - PDF417
Scan Pattern:
  • Single Line
  • 2D Raster
  • Omni-directional
  • Semi Omni-directional
Interfaces/Ports
Host Interface:
Serial
Power Description
Input Voltage:
5.2 V DC
Physical Characteristics
Color:
Black
Weight (Approximate):
12 oz
Miscellaneous
Additional Information:

USB Cable separate

Certifications & Standards:

Electrical Safety:

  • UL 1950
  • CSA C22.2 No. 950 EN60950/IEC950

EMI/RFI:

  • FCC Part 15 Class B
  • ICES-003 Class B
  • European Union EMC Directive
  • Australian SMA

Laser Safety:

  • CDRH Class ll
  • IEC Class 2
Warranty
Limited Warranty:
3 Year
Item Numbers
UNSPSC: 43211701
Get help from a Barcoding Expert!

What type of Barcode are you scanning?

The Symbol M2004-I500 Barcode Scanner is also known as SYM-M2004I500 or M2004I500.
