Symbol LS 7708 – Barcode Scanner – 1D

Part Number: LS7708-BENK0100AR
Model: LS 7708
Add to My Shopping List Add to Compare
Discontinued Need Assistance?

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

Scanner Capability
1D

Product Description:

  Keyboard Wedge kit: Includes PS/2 cable, power supply and AC line cord, EAS Antenna. Color: Black. RoHS Compliant.
Explore all Symbol LS 7708 Barcode Scanners
Add to Quote
Symbol LS7708-BENK0100AR Barcode Scanner
Symbol LS7708-BENK0100AR Barcode Scanner
Symbol LS7708-BENK0100AR Barcode Scanner
Symbol LS7708-BENK0100AR Barcode Scanner
Symbol LS7708-BENK0100AR Barcode Scanner Symbol LS7708-BENK0100AR Barcode Scanner Symbol LS7708-BENK0100AR Barcode Scanner Symbol LS7708-BENK0100AR Barcode Scanner
Full specifications (PDF)

Symbol LS 7708 Barcode Scanner Model Overview

The LS 7708 mini-slot scanner is the perfect choice for retailers looking for higher throughput and increased productivity. The on-counter LS 7708 is available for presentation or swipe scanning in an attractive form factor. For fast, accurate merchandise scanning at checkout, this easy-to-use, hands-free scanner requires minimal operator effort. Every feature contributes to increased performance for more efficient, rapid customer checkouts.
Symbol LS7708-BENK0100AR Barcode Scanner Overview

Moving customers through checkout quickly is one of the most important issues faced by retailers today. The LS7708 Bar Code Reader from Symbol is the perfect choice for retailers looking for higher throughput and increased productivity. For fast, accurate merchandise scanning at checkout, this easy-to-use, hands-free scanner requires minimal operator effort. Every feature contributes to increased performance for more efficient, rapid customer checkouts.

Full specifications (PDF)
Technical Information
Connectivity Technology:
Cable
Barcode Symbology Supported:
  • UPC/EAN/JAN
  • UPC/EAN Supplementals
  • UCC/EAN 128
  • Code 128
  • ISBT 128
  • Code 39
  • Code 39 TriOptic
  • Interleaved 2 of 5
  • Discrete 2 of 5
  • Code 93
  • Code 11
  • RSS Variants
  • Codabar
Light Source:
Laser
Scan Rate:
2400 scan/s
Maximum Scan Resolution:
5 mil
Depth of Field:
  • 0.5" - 2.5"@5mil
  • 0" - 5"@7.8mil
  • 0" - 7.5"@10.4mil
  • 0" - 10"@13mil - 100% UPC/EAN
Scan Pattern:
Omni-directional
Cable Type Included:
PS/2
Interfaces/Ports
Host Interface:
Multi-interface
Power Description
Input Voltage:
5.5 V DC
Power Supply Included:
Yes
Physical Characteristics
Form Factor:
Desktop
Color:
Black
Height:
6.3"
Width:
6"
Depth:
3.7"
Weight (Approximate):
2 lb
Miscellaneous
Package Contents:
  • Symbol LS 7708 Bar Code Reader
  • EAS Antenna
  • 6' Straight Keyboard Wedge PS/2 Cable
  • 7.5' US Battery Charger
  • AC Line Cord
  • 120V AC Power Supply
Additional Information:

Supported Interfaces:

  • USB
  • Serial
  • IBM 468X/469X
  • Keyboard Wedge
  • Synapse

USB Cable separate

Certifications & Standards:

RoHS Compliance

Electrical Safety:

  • UL 1950
  • CSA C22.2 No. 950
  • EN60825

Laser Safety:

  • CDRH Class IIa
  • IEC 60825 Class 1

EMC:

  • CISPR B
  • FCC B
Environmentally Friendly:
Yes
Environmental Certification:
RoHS
Warranty
Limited Warranty:
2 Year
Item Numbers
GTIN: 0132017662398
UPC: 132017662398
EAN: 0132017662398
UNSPSC: 43211701
Get help from a Barcoding Expert!

What type of Barcode are you scanning?

The Symbol LS7708-BENK0100AR Barcode Scanner is also known as SYM-LS7708BENK0100AR or LS7708BENK0100AR.
