Symbol LS4208-SR20007ZCR Barcode Scanner

Motorola DS4308-HD00007ZCWW Barcode Scanner A newer version of this item is available.
It is replaced by the Motorola DS4308-HD00007ZCWW Barcode Scanner.
Symbol LS4208 - SCANNER ONLY, 1D Laser, Checkpoint EAS. Cables and accessories must be purchased separately. Color: Black.
  • Speed up customer's checkout experience
  • Wired connectivity makes this scanner ideal for retail and desktop applications
  • Laser scan engine guarantees rapid error free data entry
Read More
Discontinued See Replacement
Add to Quote
Symbol LS4208 Barcode Scanner Model Overview
The LS4208 is the next generation of Symbol's best selling LS4000 laser scanner series. Designed to increase efficiencies in scan-intensive operations, the LS4208 laser handheld scanner accelerates throughput with productivity-enhancing features never before delivered by a single scanner. It offers continuous, one-pass scanning, allowing novice and advanced users alike to process more items more rapidly and spend less time keying in data. With its innovative multi-line rastering scan pattern, the Symbol LS4208 enables the quick and accurate scanning of all types of one-dimensional (1D) symbologies, including damaged symbols and stacked reduced space symbology (RSS) barcodes. It also provides a wide working range and superior motion tolerance to increase scanning flexibility and performance. Choose from a variety of interfaces, including USB, RS232 and Keyboard Wedge.
Symbol LS4208-SR20007ZCR Barcode Scanner Overview

With Symbol's LS4208 handheld laser bar code scanner, you are able to effortlessly speed throughput, even with bar codes in poor condition. Wherever you need to quickly capture and process data such as at the retail checkout counter, in pharmacies and hospitals, and in light warehouse environments this ergonomically designed scanner helps you increase accuracy, improve productivity, cut maintenance costs and reduce the risk of downtime. The LS4208 features Checkpoint Electronic Article Surveillance (EAS) which offers dual functionality to improve return on investment and save critical counter space.

Technical Information
Connectivity Technology:
Cable
Scanning Capability:
1D
Barcode Symbology Supported:
  • UPC/EAN Supplementals
  • Code 39
  • Code 39 Full ASCII
  • Trioptic Code 39
  • RSS Variants
  • UCC/EAN 128
  • Code 128
  • Code 128 Full ASCII
  • Code 93
  • Codabar (NW1)
  • Interleaved 2 of 5
  • Discrete 2 of 5
  • MSI
  • Code ll
  • IATA
  • Bookland EAN
  • Code 32
Light Source:
Laser
Maximum Scan Resolution:
5 mil
Depth of Field:
  • 1.5" - 5.5"@5mil - Code 39
  • 0" - 14"@10mil - Code 39
  • 0" - 19"@13mil - 100% UPC/EAN
  • 0" - 29"@20mil - Code 39
Scan Pattern:
2D Raster
Interfaces/Ports
Host Interface:
Multi-interface
Power Description
Input Voltage:
5 V DC
Physical Characteristics
Color:
Black
Height:
6.7"
Width:
2.7"
Depth:
3.7"
Weight (Approximate):
6.40 oz
Miscellaneous
Additional Information:

Supported Interfaces:

  • Serial
  • IBM 468X/469X
  • Keyboard Wedge
  • USB
  • Wand Emulation

USB Cable separate

Certifications & Standards:
  • RoHS

Electrical safety:

  • UL1950
  • CSA C22.2 No. 950
  • EN60950/IEC950

Laser safety:

  • CDRH Class II
  • IEC Class 2

EMI/RFI:

  • FCC Part 15 Class B
  • ICES-003 Class B
  • European Union EMC Directive
  • Australian SMA
Environmentally Friendly:
Yes
Environmental Certification:
RoHS
Warranty
Limited Warranty:
5 Year
Item Numbers
GTIN: 0766150037203
UPC: 766150037203
EAN: 0766150037203
UNSPSC: 43211701
Get help from a Barcoding Expert!

What type of Barcode are you scanning?

The Symbol LS4208-SR20007ZCR Barcode Scanner is also known as SYM-LS4208SR20007ZCR or LS4208SR20007ZCR.
