Symbol LS4208 – Barcode Scanner – Corded – 1D

Part Number: LS4208-SBZR0100AR
Model: LS4208
Discontinued Need Assistance?
Item on backorder — chat for lead time

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Connectivity
Corded
Form Factor
Handheld
Interface Options
Serial
Scanner Capability
1D

Product Description:

  RS-232 Serial Kit, 1D Laser. Includes RS-232 Serial cable and power supply. Color: Black

Motorola LS4208 Barcode Scanner Model Overview

The LS4208 is the next generation of Motorola's best selling LS4000 laser scanner series. Designed to increase efficiencies in scan-intensive operations, the LS4208 laser handheld scanner accelerates throughput with productivity-enhancing features never before delivered by a single scanner. It offers continuous, one-pass scanning, allowing novice and advanced users alike to process more items more rapidly and spend less time keying in data. With its innovative multi-line rastering scan pattern, the Motorola LS4208 enables the quick and accurate scanning of all types of one-dimensional (1D) Motorola ogies, including damaged Motorola s and stacked reduced space Motorola ogy (RSS) barcodes. It also provides a wide working range and superior motion tolerance to increase scanning flexibility and performance. Choose from a variety of interfaces, including USB, RS232 and Keyboard Wedge.
Symbol LS4208-SBZR0100AR Barcode Scanner Overview

Symbol LS4208 handheld laser scanner accelerates with breakthrough productivity-enhancing features, including continuous one-pass scanning. It also offers features not found in other available scanners. It rapidly scans all types of one-dimensional (1D) bar codes, including damaged symbols or stacked symbology (RSS) bar codes.

Technical Information
Connectivity Technology:
Cable
Scanning Capability:
1D
Barcode Symbology Supported:
  • RSS
  • UPC/EAN Supplementals
  • Code 39
  • Code 39 Full ASCII
  • Trioptic Code 39
  • RSS Variants
  • UCC/EAN 128
  • Code 128
  • Code 128 Full ASCII
  • Code 93
  • Codabar (NW1)
  • Interleaved 2 of 5
  • Discrete 2 of 5
  • MSI
  • Code ll
  • IATA
  • Bookland EAN
  • Code 32
Light Source:
Laser
Maximum Scan Resolution:
5 mil
Depth of Field:
  • 1.5" - 5.5"@5mil - Code 39
  • 0" - 19"@13mil - 100% UPC/EAN
  • 0" - 14"@10mil - Code 39
  • 0" - 29"@20mil - Code 39
Scan Pattern:
Multi Line
Interfaces/Ports
Host Interface:
Serial
Power Description
Input Voltage:
5 V DC
Power Supply Included:
Yes
Physical Characteristics
Color:
Black
Height:
6.7"
Width:
2.7"
Depth:
3.7"
Weight (Approximate):
6.38 oz
Miscellaneous
Package Contents:
  • Symbol LS 4208 Bar Code Reader
  • 110 Power Supply
  • 7ft. RS-232 Straight Cable
Additional Information:

USB Cable separate

Certifications & Standards:
  • RoHS Compliance

Electrical Safety:

  • UL1950
  • CSA C22.2 No. 950
  • EN60950/IEC950

Laser Safety:

  • CDRH Class II
  • IEC Class 2

EMI/RFI:

  • FCC Part 15 Class B
  • ICES-003 Class B
  • European Union EMC Directive
  • Australian SMA
Environmentally Friendly:
Yes
Environmental Certification:
RoHS
Warranty
Limited Warranty:
5 Year
Item Numbers
GTIN: 0024606509057, 0682017471938, 0886201966259
UPC: 024606509057, 682017471938, 886201966259
EAN: 0024606509057, 0682017471938, 0886201966259
UNSPSC: 43211701
