StarTech VS321HDBTK Network Switch

StarTech - StarTech.com HDMI Extender over CAT6/5e with 3 Port Video Switch 4k 30Hz/115ft, 4K HDMI Switch Box, Video over HDBaseT with Auto Switcher, HDMI Over CAT6 Extender w/ 3 Port Switch; 4K 30Hz/115ft (35m); 1080p/230ft (70m) over CAT5e/6; Manual/Priority/Auto Switching; Multiple Control Methods; Power over Cable; HDBaseT; TAA Compliant; IR Remote (No Batteries incl.); Mounting Brackets Incl.
  • HDMI EXTENDER WITH SWITCH: This 3 Port HDMI Switch Box extends 4K 30Hz resolutions up to 115ft (35m) or 1080p up to 230ft (70m) using CAT6/CAT5e cabling | Receiver Unit included | 4:4:4 Chroma Subsampling | 7.1ch Audio | HDCP 1.4 | HDBaseT | TAA Compliant
  • HDBASET CERTIFIED: 4K HDMI Automatic Switch and Extender is tested and certified by the HDBaseT Alliance to help ensure quality and compatibility | Great for Digital Signage and AV installers/integrators for commercial and professional environments
  • CONFIGURATION AND CONTROL: Manual, Priority or Auto-Detect Switching Options | Push Button, IR Remote Control (Batteries Not Included) and Serial Commands allow for a variety of control options | Manual or Auto EDID Copy
  • SINGLE POWER ADAPTER FLEXIBILITY: The power adapter can be placed at either the remote or local side in areas where power outlets may be limited; Power is delivered to the HDMI Video Switcher transmitter and receiver kit over the Ethernet cable (PoC)
  • EASY INSTALLATION: Durable metal housing with built-in grounding bolts and included optional mounting brackets make it ideal for many environments. The unit features DB9 RS232 ports for serial control, an RJ11 cable and an RJ11 to DB9 adapter is included
Read More
$554.58
Add to Quote
Technical Information
Connectivity Technology:
Wired
Number of Input Devices Supported:
3
Maximum Operating Distance:
230 ft
Video
Graphics Modes:
4K
Maximum Video Resolution:
4096 x 2160
Interfaces/Ports
Network (RJ-45):
Yes
HDMI In:
Yes
HDMI Out:
Yes
Number of Network (RJ-45) Ports:
2
Number of HDMI Inputs:
3
Number of HDMI Outputs:
1
Media & Performance
Media Type Supported:
Twisted Pair
Twisted Pair Cable Standard:
Category 6
Power Description
Power Plug Type:
Type M
Physical Characteristics
Product Color:
Black
Receiver Height:
1.30"
Receiver Width:
4.10"
Receiver Depth:
6.30"
Form Factor:
Desktop
Receiver Weight (Approximate):
1.30 lb
Miscellaneous
Package Contents:
  • HDMI Extender
  • HDMI Receiver
  • Remote Control
  • Universal Power Adapter (NA/JP, UK, EU, ANZ)
  • RJ11 Cable
  • RJ11 to RS232 Converter
  • Set of Mounting Screws
  • Quick-Start Guide
  • Mounting Brackets
  • Rubber Feet
Application/Usage:
  • Digital Signage System
  • Display
Environmentally Friendly:
Yes
Environmental Certification:
  • WEEE
  • RoHS
  • REACH
Country of Origin:
Taiwan
TAA Compliant:
Yes
Warranty
Limited Warranty:
2 Year
Item Numbers
GTIN: 0065030880091
UPC: 065030880091
EAN: 0065030880091
UNSPSC: 43211601
