Star BSH-20U – Barcode Scanner – 1D, 2D – Medium Range

Part Number: 37950930
Model: BSH-20U
Add to My Shopping List Add to Compare
$140.12
In Stock

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Form Factor
Handheld
Interface Options
USB
Scanner Capability
1D, 2D
Scanner Type
Imager

Product Description:

  Barcode Scanner, Star BSH-20U, Handheld, 1D/2D Imager, USB Cable, White, Includes Stand, mC-Print and mPOP Compatible
Explore all Star BSH-20U Barcode Scanners
Add to Quote
Star 37950930 Barcode Scanner
Star 37950930 Barcode Scanner
Star 37950930 Barcode Scanner
Star 37950930 Barcode Scanner Star 37950930 Barcode Scanner Star 37950930 Barcode Scanner
Full specifications (PDF)

Star BSH-20U Barcode Scanner Model Overview

Elevate your business efficiency with the BSH-20U Handheld Barcode Scanner from Star Micronics. This high-performance 1D/2D barcode scanner combines reliability, accuracy, and affordability, making it an essential tool for any retail or hospitality environment. With its advanced CPU, the BSH-20U seamlessly captures a variety of barcodes, including high-density, distorted, and digital formats. Its durable IP42-rated construction ensures resistance against dust and moisture, while its stylish, ergonomic design is available in sleek black or crisp white, perfect for modern point-of-sale setups. Enjoy peace of mind with a standard 2-year warranty and robust customer support.


Key Features
  • High-Performance: Equipped with a powerful CPU for capturing high-density and distorted barcodes.
  • Durable Construction: IP42-rated design, resistant to dust and moisture; drop-resistant up to 1.2m.
  • Stylish Design: Modern aesthetic available in shiny black or crisp white.
  • Cost-Efficient: Offers 2D scanning capabilities at the price of a 1D scanner.
  • User-Friendly: Easily plugs directly into Star's mCollection products.
  • Star-Branded: Guaranteed superior quality and reliability.

Specifications
  • Type: Wired Barcode Scanner
  • Sealing: IP42
  • Image Sensor: 640x480 CMOS
  • Color: Black or White
  • Resolution: ≥3mil
  • Symbologies - 2D: PDF417, QR Code, Data Matrix, and more.
  • Symbologies - 1D: Code 128, UPC-A, EAN-13, and others.
  • Connectivity/Interface: RS-232, USB
  • Dimensions: 146×103×69 mm | Weight: 125g
  • Typical Depth of Field: EAN-13: 50 mm-260 mm (13 mil)
  • Scan Angle: Pitch: ±55°, Skew: ±55°, Roll: 360°
  • Field of View: Horizontal 45°, Vertical 34°
  • Drop Resistance: 1.2m
  • Warranty: 2 Year
Star 37950930 Barcode Scanner Overview
Equipped with a high-power CPU, this 1D/2D handheld scanner effortlessly captures high-density, high-volume, and distorted barcodes printed on paper or displayed on screen. Scanner stand included.
Full specifications (PDF)
Technical Information
Connectivity Technology:
Cable
Scanning Capability:
  • 1D
  • 2D
Barcode Symbology Supported:

2D:

  • PDF417
  • Micro PDF417
  • Micro QR
  • QR Code
  • Data Matrix
  • Aztec

1D:

  • Code 11
  • Code 128
  • Code 39
  • GSl-128 (UCC/EAN 128)
  • AIM 128
  • ISBT 128
  • Codabar
  • Code 93
  • UPC-A
  • UPC-E
  • Coupon
  • GS1 Composite
  • EAN-8
  • EAN-13
  • ISBN/ISSN
  • Interleaved 2 of 5
  • Matrix 2 of 5
  • Industrial 25
  • ITF6
  • ITF-14
  • Standard 25
  • China Post 25
  • MSI Plessey
  • Plessey
  • GSl Data bar (RSS)
Image Sensor Type:
CMOS
Scanning Distance:
10.24"
Stand Included:
Yes
Field of View (Horizontal):
45°
Field of View (Vertical):
34°
Reading Angle (Skew):
55°
Reading Angle (Pitch):
55°
Reading Angle (Roll):
360°
Drop Specification:
1.2m
Minimum Print Contrast:
0.2%
Minimum Element Resolution (Code 39):
5 mil
Maximum Element Resolution (DataMatrix):
15 mil
Maximum Element Resolution (PDF417):
6.7 mil
Image Sensor Resolution:
640 x 480
Illumination Type:
LED
Illumination Color:
White
Interfaces/Ports
Host Interface:
USB
Environmental Conditions
Storage Temperature:
-40°F (-40°C) to 158°F (70°C)
Humidity (Non-condensing):
5% to 95%
Physical Characteristics
Form Factor:
Handheld
Product Color:
White
Height:
2.7"
Width:
4"
Length:
5.7"
Weight (Approximate):
3.92 oz
Miscellaneous
Package Contents:
  • BSH-HR2081 White Star Handheld Wired Barcode Scanner
  • Stand
Ingress Protection (IP) Rating:
  • IP42
  • IP52
Item Numbers
GTIN: 0088047275117
UPC: 088047275117
EAN: 0088047275117
UNSPSC: 43211701

Frequently Asked Questions

The Star BSH-20U offers universal compatibility and supports most Star and third-party handheld barcode scanners. It can be directly plugged into Star's mCollection® products, including mC-Print2/3 and mPOP®, making it a versatile solution for mixed scanner environments. Contact us today to confirm compatibility with your specific scanner model.

Yes, the BSH-20U is specifically designed for high-volume retail, warehouse, and office settings with robust construction built for commercial environments with frequent use. Its weighted base prevents unwanted movement or tipping during busy shifts, and the hands-free operation capability enables faster, more efficient barcode scanning without holding the scanner manually.

The BSH-20U features an IP42-rated design and is drop-resistant from 1.2 meters, making it suitable for demanding warehouse and retail environments. Its robust, heavy-duty construction ensures reliable performance even with frequent daily use in commercial settings.

The BSH-20U's flexible gooseneck design easily adjusts to multiple angles, allowing you to position your barcode scanner exactly where you need it for optimal ergonomics and workflow efficiency. This adjustability promotes faster transactions and reduces strain on employees during checkout or workstation operations.

Yes, the BSH-20U is ideally suited for a wide range of markets, including retail, hospitality, inventory management, and online ordering. Its versatile and adaptable design makes it effective whether used at a checkout counter, warehouse workstation, or office environment.

The Star BSH-20U comes with a scanner stand included in the package. Available from us in both shiny black and crisp white finishes to align with modern point-of-sale (POS) setups. Visit barcodesinc.com to order yours today.

The Star 37950930 Barcode Scanner is also known as STA-37950930 or 37950930.
