Socket Mobile – Barcode Scanner – Scanner Only

Part Number: CX4039-3102
Model: Parts
3-year Premium Plus ($54.70)
No, stay at premium support package
Add to My Shopping List Add to Compare
$327.75
Item on backorder — chat for lead time

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Connectivity Technology
Wireless
Scanning Capability
1D2D
Barcode Symbology Supported
1D: Codabar Code 39 Code 93 Code 128 EAN-13 EAN-8 Interleaved 2 of 5 ISBT 128 UPC A UPC E1 Chinese 2 of 5 Codabar Code 11 Code 16KCode 39 Code 93 Code 128 Discrete 2 of 5 EAN-13 EAN-8 GS1 Databar Industrial 2 of 5 Interleaved 2 of 5 Matrix 2 of 5 MSI Plessey UPC A UPC E1 Standard 2 of 5 UK Plessey 2D: Data Matrix Micro QR Code PDF417 QR Code Aztec Data Matrix Han Xin Micro PDF417 Micro QR Code PDF417 QR Code
Light Source
LED

Product Description:

  Barcode Scanners, Socket-Mobile, Socketscan S820, Black
Explore all Socket Mobile Parts Accessories
Add to Quote
Socket Mobile CX4039-3102 Barcode Scanner
Socket Mobile CX4039-3102 Barcode Scanner
Socket Mobile CX4039-3102 Barcode Scanner
Socket Mobile CX4039-3102 Barcode Scanner
Socket Mobile CX4039-3102 Barcode Scanner
Socket Mobile CX4039-3102 Barcode Scanner Socket Mobile CX4039-3102 Barcode Scanner Socket Mobile CX4039-3102 Barcode Scanner Socket Mobile CX4039-3102 Barcode Scanner Socket Mobile CX4039-3102 Barcode Scanner

Socket Mobile Parts Accessory Model Overview

Products and parts from Socket-Mobile.
Socket Mobile CX4039-3102 Barcode Scanner Overview
Linear Barcode Plus QR Code Scanner

The Socket Mobile S820 is a 1D/2D linear barcode & QR Code barcode reader with Bluetooth wireless technology. Small, thin and easy to use, the reader is optimized for attaching to mobile devices, enabling one-handed operation. The S820 can scan barcodes printed on labels or displayed on device screens. It reads the most popular 2D/1D barcodes and is perfect for retail point of sale, inventory management, sales order entry, field service, and other mobile business applications.

Approximately the same size as a credit card, measuring less than ½ inch (1.27cm) thick and weighing less than two ounces, the S820 is one of the smallest and lightest high quality barcode reader available in the market today. The S820 slips neatly into your pocket and fits comfortably in the palm of your hand when attached to a smartphone. It is compatible with all applications used with other Socket Mobile readers with "NO" software update required.
Technical Information
Connectivity Technology:
Wireless
Scanning Capability:
  • 1D
  • 2D
Barcode Symbology Supported:
1D:
  • Codabar
  • Code 39
  • Code 93
  • Code 128
  • EAN-13
  • EAN-8
  • Interleaved 2 of 5
  • ISBT 128
  • UPC A
  • UPC E1
  • Chinese 2 of 5
  • Codabar
  • Code 11
  • Code 16KCode 39
  • Code 93
  • Code 128
  • Discrete 2 of 5
  • EAN-13
  • EAN-8
  • GS1 Databar
  • Industrial 2 of 5
  • Interleaved 2 of 5
  • Matrix 2 of 5
  • MSI Plessey
  • UPC A
  • UPC E1
  • Standard 2 of 5
  • UK Plessey
2D:
  • Data Matrix
  • Micro QR Code
  • PDF417
  • QR Code
  • Aztec
  • Data Matrix
  • Han Xin
  • Micro PDF417
  • Micro QR Code
  • PDF417
  • QR Code
Light Source:
LED
Scan Pattern:
Linear
Scanning Distance:
15"
Cable Type Included:
USB
Field of View (Horizontal):
45°
Field of View (Vertical):
34°
Maximum Ambient Light:
100000 lux
Drop Specification:
Multiple drops to vinyl covered concrete at about 3 ft or 1 m
Minimum Print Contrast:
25%
Maximum Element Resolution (Code 39):
5 mil
Maximum Element Resolution (DataMatrix):
10 mil
Network & Communication
Bluetooth:
Yes
Interfaces/Ports
Host Interface:
USB
Battery Information
Battery Included:
Yes
Battery Weight:
0.44 oz
Physical Characteristics
Form Factor:
Handheld
Color Family:
Black
Product Color:
Black
Weight (Approximate):
1.69 oz
Miscellaneous
Package Contents:
  • S820 Barcode Scanner
  • Rechargeable Battery (pre-installed)
  • Micro USB Charging
  • Cable
  • Universal Klip Case
Ingress Protection (IP) Rating:
IP40
Application/Usage:
  • Retail
  • Hospitality
  • Logistics
  • Healthcare
  • Inventory
  • Transportation
  • Warehouse
  • Field Sales/Service
Platform Supported:
  • iOS
  • Android
  • PC
  • Mac
Country of Origin:
United States
Warranty
Limited Warranty:
1 Year
Additional Warranty Information:
optional extended warranty available.
Item Numbers
GTIN: 0758497122148
UPC: 758497122148
EAN: 0758497122148
UNSPSC: 43211701

Frequently Asked Questions

The Socket Mobile CX4039-3102 is a wireless handheld barcode scanner designed for mobile data capture in warehouse, logistics, and inventory management environments. It delivers reliable barcode reading performance for operations that require portable scanning solutions. We offer this scanner as part of our comprehensive AIDC product lineup available from barcodesinc.com.

Yes, the CX4039-3102 is a wireless handheld barcode scanner that enables mobile scanning without the constraints of corded connections. This makes it ideal for warehouse managers and logistics professionals who need flexibility and mobility during inventory operations. Contact us today to learn more about wireless scanning solutions we offer.

The Socket Mobile CX4039-3102 is a handheld barcode scanner from Socket Mobile, engineered for mobile and wireless scanning applications. It falls within our mobile barcode scanner category and is suitable for professionals requiring portable scanning capabilities in dynamic work environments. Visit barcodesinc.com to explore our full range of Socket Mobile scanning solutions.

The CX4039-3102 is part of Socket Mobile's current barcode scanner lineup and represents the manufacturer's modern scanning technology. If you're upgrading from a previous Socket Mobile model, our team can help you assess compatibility and integration with your existing systems. Contact us today for guidance on scanner upgrades and transitions.

The Socket Mobile CX4039-3102 is manufactured by Socket Mobile, a recognized producer of mobile data capture devices and barcode scanning solutions. We carry Socket Mobile products as part of our extensive inventory of leading AIDC equipment available from barcodesinc.com.

We offer the Socket Mobile CX4039-3102 barcode scanner as part of our complete AIDC product selection. Visit barcodesinc.com or contact us today to check availability, pricing, and to discuss which scanning solution best fits your warehouse or logistics operation.

The Socket Mobile CX4039-3102 Barcode Scanner is also known as SOC-CX40393102
