Socket Mobile AC4000-514 Spare Parts

Part Number: AC4000-514
Model: Parts
Add to My Shopping List Add to Compare
Discontinued Need Assistance?

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Media Supported
CompactFlash Type I
Host Interface
PC Card Type I
Height
0.2"
Width
2.1"

Product Description:

  Socket Communications CompactFlash-to-PC Card Adapter - DISCONTINUED - PC Card Type I
Explore all Socket Mobile Parts Accessories
Add to Quote
Socket Mobile AC4000-514 Spare Parts
Socket Mobile AC4000-514 Spare Parts

Socket Mobile Parts Accessory Model Overview

Products and parts from Socket-Mobile.
Socket Mobile AC4000-514 Spare Parts Overview

Add Versatility to Your CompactFlash Card with Socket's PC Card Adapter:
Get more mileage out of your CompactFlash card with Socket's CompactFlash-to-PC Card Adapter. Most mobile computers have either a CompactFlash I/O or PC Card (PCMCIA) slot. Socket's Type I CompactFlash-to-PC Card Adapter converts your Type I CompactFlash card into a Type I PC Card,so you can also use it in a Type I, II or III PC Card slot. This eliminates the hassle and cost of buying multiple cards to use with your different types of mobile computers. Plus, if the card you need is available only in the CompactFlash form factor, now you don't have to worry about compatibility issues with a PC Card slot.

Technical Information
Media Supported:
CompactFlash Type I
Host Interface:
PC Card Type I
Physical Characteristics
Height:
0.2"
Width:
2.1"
Depth:
3.4"
Miscellaneous
Additional Information:

Features:

  • Type: Dual-row at mating section
  • Temperture Range: -40 °C to +85°C (includes temperature rise in applying electrical current)
  • Contact Resistance: Initial value/ 40Ohm max After environmental testing/ max. 20m Ohm variation from initial value
  • Insulation Resistance: 1,000 M Ohm min. (500 V DC)
  • Mating/unmaking life: 10,000 cycles
  • Pins: 50 pins
  • Conforms to CompactFlash Adapter (CFA) standards

Material and Finish:

  • 50-pin side header: phosphor bronze, nickel-undercoated contact with gold-plated mating section and tin/leadplated solder; PPS, UL94V-0 housing
  • 68-pin side socket: beryllium copper, nickel-undercoated contact with a gold-plated mating section and tin/lead plated contact; LCP, UL94V-0 housing; phosphor bronze grounding spring with nickel undercoat and gold-plating
Warranty
Limited Warranty:
90
Item Numbers
GTIN: 0758497040008
UPC: 758497040008
EAN: 0758497040008
UNSPSC: 43201552
Get help from a Barcoding Expert!

What type of Barcode are you scanning?

The Socket Mobile AC4000-514 Spare Parts is also known as SOC-AC4000-514 or AC4000514.
