SIIG CE-H27D11-S1 Network Switch

SIIG - SIIG 4K 60Hz HDMI Over Cat6 Extender with Loopout & IR, HDMI 4K60Hz 4:4:4 8-bit / 4K60Hz HDR 4:2:0 10-bit Extender, Extends HDMI signals up to 230ft (70m) over a single Cat6/7 cable with a local HDMI output for monitoring the extended display, 18Gbps video bandwidth, Nearly zero latency, 3.5mm audio extraction, 21:9 wide monitor 3440x1440 resolution support, Auto Downscaling 4K60Hz to 1080p 60Hz, IR / EDID passthrough, ESD/Lightning/Surge protection, Metal housing, 2 years warran
  • Extends HDMI signals from DVD players, game consoles, or HDMI-equipped computers up to 230ft via Cat6/7 networking cable, ideal for home theater, conference room or other audio/video applications that require remote location setup
  • Delivers video content up to UHD 4K@60Hz with zero latency up to 230ft/70m through a Cat6/7 network cable, support HDR 10
  • The transmitter can work as an HDMI splitter with the additional HDMI output design and allows screen mirroring to another display device
  • Supports PCM / DTS-HD/ Dolby Digital 5.1ch via HDMI and 3.5mm stereo audio from receiver
  • Supports EDID passthrough and auto downscaling
  • Lightning Protection, Surge Protection, ESD Protection provides durability and minimizes EMI/RFI noise interference.
  • Premium metal housing offers excellent heat dissipation further enhances durability for dependable performance and long life
  • Plug-n-Play installation, no software installation or hardware setup is required
Read More

Need a different version? See all SIIG Parts Products

$144.25
In Stock
Chat Now for Qty Discount
Add to Quote
Add to My Shopping List Add to Compare
SIIG CE-H27D11-S1 Network Switch
SIIG CE-H27D11-S1 Network Switch
SIIG Parts Products Model Overview
Products and parts from SIIG.
SIIG CE-H27D11-S1 Network Switch Overview

Multiple Connectivity Ports
Comes with one HDMI video input port, one HDMI video loop-out port, one HDMI video output port, two RJ45 network ports, one 3.5mm IR emitter port, one 3.5mm IR receiver port, one 3.5mm stereo audio port, two reset buttons, two DC power jacks (5V/1A)

Applications

  • Lecture hall
  • Educational facilities
  • Multimedia education
  • Home theater
  • Restaurant
  • Shopping center
  • Digital signage
  • Meeting room
  • Trade show
  • Library
  • Show room
  • Church
Technical Information
Connectivity Technology:
Wired
Number of Input Devices Supported:
1
Number of Output Devices Supported:
2
Maximum Operating Distance:
230 ft
Video
Graphics Modes:
4K
Interfaces/Ports
Network (RJ-45):
Yes
HDMI In:
Yes
HDMI Out:
Yes
Number of Network (RJ-45) Ports:
2
Number of HDMI Inputs:
1
Number of HDMI Outputs:
2
Media & Performance
Media Type Supported:
Twisted Pair
Twisted Pair Cable Standard:
Category 7
Power Description
Frequency:
  • 50 Hz
  • 60 Hz
Physical Characteristics
Product Color:
Black
Transmitter Height:
0.65"
Transmitter Width:
3.35"
Transmitter Depth:
2.97"
Receiver Height:
0.65"
Receiver Width:
3.35"
Receiver Depth:
2.97"
Transmitter Weight (Approximate):
4.80 oz
Receiver Weight (Approximate):
4.80 oz
Miscellaneous
Package Contents:
  • 1 x Transmitter
  • 1 x Receiver
  • 2 x Power Adapter
  • IR Blaster extension cable
  • IR Receiver extension cable
  • 4 x Mounting Ears
  • 8 x Screws
  • User Manual
Environmentally Friendly:
Yes
Environmental Certification:
RoHS
Country of Origin:
China
Warranty
Limited Warranty:
2 Year
Item Numbers
GTIN: 0662774045382
UPC: 662774045382
EAN: 0662774045382
UNSPSC: 45111815
