SIIG CE-H26L11-S1 Network Switch

SIIG - SIIG ipcolor 4K HDMI 2.0 Extender with IR, HDR and ARC, 3840x2160 60Hz HDMI Extender with IR, 18Gbps video bandwidth distance up to 230ft (70m) with zero latency, 1 in 2 out, support loopout, HDMI over Cat6 Extender / HDR / HDCP 2.2 / S/PDIF Audio Extraction or ARC / Bi-directional IR / EDID Switch /ESD Protection / Reset Button / Lightning Protection / Surge Protection, Aluminum alloy housing, 2x IR Extension Cable, Wall Mountable, 2 years warranty

Need a different version? See all SIIG Parts Products

$166.45
In Stock
Chat Now for Qty Discount
Add to Quote
Add to My Shopping List Add to Compare
SIIG CE-H26L11-S1 Network Switch
SIIG CE-H26L11-S1 Network Switch
SIIG Parts Products Model Overview
Products and parts from SIIG.
SIIG CE-H26L11-S1 Network Switch Overview

Extends 4K@60Hz HDMI signals up to 230ft with zero latency, IR, HDR, audio extraction, local HDMI out, and ARC using industry leading ipcolor video transmission technology

  • 4K HDMI Extension - Extends UHD 4K@60Hz HDMI signals up to 230ft/70m from a source device to an HDMI display via Cat6/6a/7 cable
  • Advanced ipcolor Transmission Technology - ipcolor is a global leading innovative technology for ultra high definition video digital transmission and connectivity, it can extend and transmit uncompressed 4K@60Hz YUV 4:4:4 video + audio, including HDR, with zero latency
  • Audio Extraction - Extracts digital audio from the HDMI signal and routes it through the receiver's digital S/PDIF port via PCM2, Dolby 5.1, DTS 5.1 audio signal
  • IR Control - Built-in bi-directional IR provides full remote control capabilities, control the HDMI source device at the remote display location and vice versa
  • Auto EDID and Downscaling - The lowest EDID capability of the connected display(s) controls the resolution output to the display(s)
  • Protection - Lightning Protection, Surge Protection, ESD Protection
  • High Quality Design - High quality metal housing with ventilation panels improve heat dissipation and ensure system stability during long hours of operation
  • Easy Installation - Plug and play installation, no driver installation required

More from the Manufacturer

Technical Information
Connectivity Technology:
Wired
Number of Input Devices Supported:
1
Maximum Operating Distance:
230 ft
Video
Graphics Modes:
4K UHD
Maximum Video Resolution:
3840 x 2160
Interfaces/Ports
Network (RJ-45):
Yes
HDMI In:
Yes
HDMI Out:
Yes
Number of Network (RJ-45) Ports:
1
Number of HDMI Inputs:
1
Number of HDMI Outputs:
1
Media & Performance
Media Type Supported:
Twisted Pair
Twisted Pair Cable Standard:
Category 7
Physical Characteristics
Product Color:
Black
Transmitter Height:
1.03"
Transmitter Width:
3.90"
Transmitter Depth:
4.17"
Transmitter Weight (Approximate):
7.36 oz
Miscellaneous
Package Contents:
  • ipcolor 4K HDMI 2.0 Extender with IR, HDR and ARC
  • 2 x Power Adapter
  • 1 x IR Blaster Cable
  • 1 x IR Receiver Cable
  • 8 x Mounting Ears and installation hardware
  • User Manual
Environmentally Friendly:
Yes
Environmental Certification:
RoHS
Country of Origin:
China
Warranty
Limited Warranty:
2 Year
Item Numbers
GTIN: 0662774044613
UPC: 662774044613
EAN: 0662774044613
UNSPSC: 43201614
