SIIG CE-H26011-S1 Network Switch

SIIG - SIIG Full HD HDMI Extender over Cat5e/6 with IR, 164ft, HDMI Extender over Cat5e/6 Extender Kit- Full HD 1080p up to 50m (164ft), TX & RX, HDMI 1080p Extender over Cat5e Cat6 with IR, Support HDMI Loopout, 10.2Gbps video bandwidth- HDCP 1.2- EDID Passthrough- IR Extension- Reset Button- 7.1-ch Audio- Wall Mountable- Aliminum Metal Housing, 2 years warranty
$83.22
In Stock
Add to Quote
SIIG Parts Products Model Overview
Products and parts from SIIG.
SIIG CE-H26011-S1 Network Switch Overview

Extends HDMI signals up to 164ft over a single CAT5e/6 cable with a local HDMI output for monitoring the extended display

  • Extends HDMI signals from DVD players, game consoles, or HDMI-equipped computers up to 164ft via Cat5e/6 networking cable, ideal for home theater, conference room or other audio/video applications that require remote location setup
  • IR remote control through CAT5e/6 allows you to control the HDMI source device at the extended display location
  • Built-in HDMI output on the transmitter allows for local monitoring of the extended display
  • Delivers high-quality audio/video transmission without compression for optimal performance, supports video resolution up to 1080p (Full HD) and 3D
  • Premium metal housing offers excellent heat dissipation further enhances durability for dependable performance and long life
  • Plug-n-Play installation, no software installation or hardware setup is required

Compatibility:
Replaces CE-H22E11-S1

More from the Manufacturer

Technical Information
Connectivity Technology:
Wired
Number of Input Devices Supported:
1
Number of Output Devices Supported:
1
Maximum Operating Distance:
164 ft
Video
Graphics Modes:
Full HD
Maximum Video Resolution:
1920 x 1080
Interfaces/Ports
Network (RJ-45):
Yes
HDMI In:
Yes
HDMI Out:
Yes
Number of Network (RJ-45) Ports:
2
Number of HDMI Inputs:
1
Number of HDMI Outputs:
2
Media & Performance
Media Type Supported:
Twisted Pair
Twisted Pair Cable Standard:
Category 6
Physical Characteristics
Transmitter Height:
0.97"
Transmitter Width:
2.60"
Transmitter Depth:
2.80"
Receiver Height:
0.97"
Receiver Width:
2.60"
Receiver Depth:
2.80"
Transmitter Weight (Approximate):
3.04 oz
Receiver Weight (Approximate):
2.88 oz
Miscellaneous
Package Contents:
  • Full HD HDMI Extender over Cat5e/6 with IR - 164ft (TX and RX units)
  • IR Blaster Cable (TX)
  • IR Receiver Cable (RX)
  • 2 x Power Adapter
  • User Reference Guide
Environmentally Friendly:
Yes
Environmental Certification:
RoHS
Country of Origin:
China
Warranty
Limited Warranty:
2 Year
Item Numbers
GTIN: 0662774043616
UPC: 662774043616
EAN: 0662774043616
UNSPSC: 45111815
