SIIG CE-H25311-S1 Ethernet Switch

Part Number: CE-H25311-S1
Model: Parts
Add to My Shopping List Add to Compare
$272.56

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Connectivity Technology
Wired
Number of Input Devices Supported
1
Number of Output Devices Supported
1
Maximum Operating Distance
394 ft

Product Description:

  SIIG HDMI 2.0 Over IP Matrix and Video Wall 4Kx2K@60Hz, Receiver, Supports Matrix Switching & Video Wall Function with the Controller (CE-H25411-S1) TAA Compliant
Explore all SIIG Parts Products
Add to Quote
SIIG CE-H25311-S1 Ethernet Switch
SIIG CE-H25311-S1 Ethernet Switch

SIIG Parts Products Model Overview

Products and parts from SIIG.
SIIG CE-H25311-S1 Ethernet Switch Overview

Extends HDMI audio/video signals through IP networks up to 394ft (120m), matrix and video wall configurable on the fly

  • HDMI 2.0a and HDCP 2.2 compliant
  • Supports HDMI input up to 4Kx2K@60Hz YUV 4:4:4 8bit, HDMI output up to 4Kx2K@30Hz
  • Flexible and scalable video broadcasting by IGMP Gigabit Ethernet Router/Switch
  • Supports 4K signals including High Dynamic Range (HDR), PoE, Bi-directional IR path, and Video Wall. Due to the video compression, some distortion may occur in HDR mode
  • Supports One-to-one, One-to-many, and Many-to-many broadcasting architecture
  • Easy DIP switch matching for multi-casting group configuration
  • Supports full frequency IR signal from 20KHz to 60KHz
  • Full Duplex RS-232 control up to 115,200 bps
  • Supports 180° and 270° clockwise image rotation
  • Designed to work with HDMI 2.0 Video Wall Over IP Multicast System - Transmitter, part # CE-H25211-S1 sold separately, and HDMI 2.0 Video Wall Over IP Multicast System - Controller, part # CE-H25411-S1 sold separately
Technical Information
Connectivity Technology:
Wired
Number of Input Devices Supported:
1
Number of Output Devices Supported:
1
Maximum Operating Distance:
394 ft
Video
Graphics Modes:
4K
Interfaces/Ports
Network (RJ-45):
Yes
HDMI In:
Yes
HDMI Out:
Yes
USB:
Yes
Number of Network (RJ-45) Ports:
1
Number of USB Ports:
2
Number of HDMI Inputs:
1
Number of HDMI Outputs:
1
Media & Performance
Media Type Supported:
Twisted Pair
Twisted Pair Cable Standard:
Category 5e
Physical Characteristics
Product Color:
Black
Receiver Height:
1.13"
Receiver Width:
4"
Receiver Depth:
7.09"
Receiver Weight (Approximate):
1.07 lb
Miscellaneous
Package Contents:
  • HDMI 2.0 Over IP Matrix and Video Wall - Receiver
  • Power Adapter 5V/2A
  • 1 x IR Receiver Cable
  • 2 x Screw Kit
  • Insert Card
  • User Manual
Country of Origin:
Taiwan
TAA Compliant:
Yes
Environmentally Friendly:
Yes
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
Warranty
Limited Warranty:
3 Year
Item Numbers
GTIN: 0662774042886
UPC: 662774042886
EAN: 0662774042886
UNSPSC: 43201614
