SIIG CE-H23H11-S1 Ethernet Switch

Part Number: CE-H23H11-S1
Model: Parts
Add to My Shopping List Add to Compare
$451.97

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Connectivity Technology
Cable
Number of Input Devices Supported
4
Device Supported
DisplayGaming ConsoleBlu-ray Disc PlayerTVComputerDVD PlayerMedia PlayerNotebookSet-top Box
Number of Displays Supported
4

Product Description:

  SIIG HDMI 2.0 4x4 Matrix with Amazon Echo Control Enabled, 4Kx2K @60Hz YUV 4:4:4, 8Bit, TAA Compliant
Explore all SIIG Parts Products
Add to Quote
SIIG CE-H23H11-S1 Ethernet Switch
SIIG CE-H23H11-S1 Ethernet Switch

SIIG Parts Products Model Overview

Products and parts from SIIG.
SIIG CE-H23H11-S1 Ethernet Switch Overview

Allows you to select and switch between any of the 4 HDMI source devices to display on any of the 4 HDMI displays simultaneously

  • Allows any of the four HDMI monitors to display content from any of the four HDMI sources simultaneously
  • Easily switch between HDMI source and display using push button, IR remote control, RS-232, and Ethernet control
  • Supports fast HDMI link response time below 3 sec for device switching
  • Supports resolution up to 4Kx2K @60Hz YUV 4:4:4, 8bit
  • Supports HDR 4Kx2K @60Hz YUV 4:2:0, 10bit
  • Supports default EDID and EDID learning of the connected displays
  • Metal housing for excellent RF shielding and heat dissipation, delivers reliable performance and long life
  • Included mounting ears let you easily mount this product on the wall or shelf
  • Works with Amazon Alexa Echo voice control for convenient device and display switching
Technical Information
Connectivity Technology:
Cable
Number of Input Devices Supported:
4
Device Supported:
  • Display
  • Gaming Console
  • Blu-ray Disc Player
  • TV
  • Computer
  • DVD Player
  • Media Player
  • Notebook
  • Set-top Box
Number of Displays Supported:
4
Video
Graphics Modes:
4K
Maximum Video Resolution:
4096 x 2160
Interfaces/Ports
HDMI In:
Yes
HDMI Out:
Yes
Connectivity (RJ-45):
Yes
Number of Connectivity (RJ-45) Ports:
1
Number of USB Ports:
1
Number of HDMI Inputs:
4
Number of HDMI Outputs:
4
Media & Performance
Maximum Operating Distance:
32.81 ft
Physical Characteristics
Form Factor:
  • Wall Mountable
  • Rack-mountable
Height:
1.7"
Width:
6.9"
Depth:
17.3"
Weight (Approximate):
5.21 lb
Miscellaneous
Package Contents:
  • HDMI 2.0 4x4 Matrix with Amazon Echo Control Enabled
  • Remote Control
  • IR Receiver
  • Power Adapter 12V/2A & power cord
  • Power Cord
  • 2 x Rack-Mounting Ears
  • 6 x Screws
  • Software CD
  • User Manual
Environmentally Friendly:
Yes
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
Country of Origin:
Taiwan
TAA Compliant:
Yes
Warranty
Limited Warranty:
3 Year
Item Numbers
GTIN: 0662774041445, 0800100225415
UPC: 662774041445, 800100225415
EAN: 0662774041445, 0800100225415
UNSPSC: 43211601
