SATO TG3 – Barcode Label Printer – 305 dpi

Part Number: WWTG40131
Model: TG312
3-year Premium Plus ($2,083.90)
3-year Premium ($1,929.90)
No Support
$5,256.90
Item on backorder — chat for lead time

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Printer Type
Industrial
Interface Options
Serial (RS-232)
Print Resolution
305 dpi
Max Print Width
3.25 inch

Product Description:

  Specialty Retail Tag and Label Printer, SATO TG3, Thermal Transfer, 305 dpi, 10 ips, 3.1" Max Print Width, 3" Core, 10" Outer Diameter, Serial/EXT (External Signal Interface). Base Model

SATO TG312 Barcode Label Printer Model Overview

The SATO TG312 of retail printers include a heavy duty print mechanism and cutter assembly which carries on the tradition of durability and performance of SATO solutions. With its 305 dpi resolution, industrial chassis and high performance processing, it tackles even the most demanding print jobs with supreme ease. Tags and labels automatically load with a touch of a single button, while sensors automatically calibrate gap or reflective markings ensuring proper print registration. The TG312 features both direct thermal and thermal transfer printing options, a 3.1" print width and 10"/second print speed.
SATO WWTG40131 Barcode Label Printer Overview

This new series of retail SATO printers include a heavy duty print mechanism and cutter assembly which carries on the tradition of durability and performance of SATO solutions. With its industrial chassis and high performance processing, it tackles even the most demanding print jobs with supreme ease. Tags and labels automatically load with a touch of a single button, while sensors automatically calibrate gap or reflective markings ensuring proper print registration.

Technical Information
Recommended Use:
Label Print
Print Color Capability:
Monochrome
Maximum Mono Print Speed:
10 in/s
Maximum Print Resolution (dpi):
305
Maximum Print Width:
3.10"
Barcode Symbology Supported:
  • UPC-E
  • JAN
  • EAN
  • Code 39
  • Code 93
  • Code 128
  • GS1-128
  • UCC/EAN 128
  • Codabar
  • NW-7
  • ITF
  • Industrial 2 of 5
  • Bookland
  • MSI
  • POSTNET
  • RSS
  • QR Code
  • Micro QR
  • PDF-417
  • Micro PDF
  • Maxi Code
  • GS1 DataMatrix
  • EAN-13
  • EAN-8
  • UPC-A
  • Matrix 2 of 5
  • EAN-8 Composite
  • EAN-13 Composite
  • UPC-A Composite
  • UPC-E Composite
  • GS1 DataBar Stacked Composite
  • GS1 DataBar Limited Composite
  • GS1 DataBar Stacked Omni-Directional Composite
  • GS1 DataBar Composite
  • GS1-128 Composite
  • GS1 DataBar Expanded Stacked Composite
  • GS1 DataBar Truncated Composite
  • GS1 DataBar Expanded Composite
Application/Usage:
Desktop
Print Technology:
Direct Thermal /Thermal Transfer
Memory
Standard Memory:
16 MB
Memory Technology:
SDRAM
Flash Memory:
8 MB
Interfaces/Ports
Serial Port:
Yes
Media Types & Handling
Media Type:
  • Roll Fed
  • Label
  • Tag
  • Fanfold
Media Sensor:
  • Transmissive Media Sensor
  • Reflective Media Sensor
Media Thickness:
13 mil
Maximum Roll Diameter:
10"
Maximum Label Width:
3.30"
Label Core Size:
4"
Power Description
Power Source:
AC Supply
Input Voltage:
  • 110 V AC
  • 220 V AC
Standby Power Consumption:
20 W
Physical Characteristics
Height:
11.8"
Width:
11.2"
Depth:
21.7"
Weight (Approximate):
35.71 lb
Miscellaneous
Platform Supported:
PC
Certifications & Standards:
  • FCC ISB Class B
  • VL60950-1(2001)
  • CSA222
  • FCC ISC
Item Numbers
UNSPSC: 43212108

Recommended Accessories

Category

  • Barcode Label Rewinder (1)
  • Printer Accessories (3)
  • SATO Barcode Label Rewinder (1)

Recommended Accessories for Model: SATO WWTG40131 Barcode Label Printer

Top Barcode Label Rewinder Purchased With SATO WWTG40131

Top Printer Accessories Purchased With SATO WWTG40131

Top SATO Barcode Label Rewinder Purchased With SATO WWTG40131

Frequently Asked Questions

The SATO WWTG40131 supports both direct thermal and thermal transfer printing, giving you flexibility for different label and tag applications. This dual-capability makes it ideal for retail environments where you may need to switch between different media types without changing equipment. We offer this model as a versatile solution for demanding retail tag and label printing needs.

The HP CF313A (826A) Original Toner Cartridge delivers a standard yield of 31,500 pages. This yield is based on ISO/IEC 19798 continuous printing standards, though actual page yields may vary considerably based on the images printed and other printing conditions.

The SATO WWTG40131 delivers a maximum print width of 3.1 inches and prints at 10 inches per second, making it suitable for high-volume retail tagging operations. With 305 dpi resolution, you get sharp, scannable barcodes and clear text on every label. This combination of speed and quality is built into the industrial chassis design we have available from us.

The HP CF313A is a magenta toner cartridge designed for color laser printing. It is sold as a single pack and is compatible with HP Color LaserJet printers that support the 826A cartridge specification.

Yes, the SATO WWTG40131 features automatic sensor calibration that detects gap or reflective markings to ensure proper print registration every time. Tags and labels load automatically with a single button press, reducing manual setup time and operator error. This automation is part of SATO's durability and performance tradition that we provide to our customers.

Yes, the HP CF313A is an original HP toner cartridge manufactured by HP. We offer genuine HP supplies to ensure optimal performance and compatibility with your HP LaserJet or Color LaserJet printer. Contact us today for authentic HP cartridges and supplies.

The SATO WWTG40131 base model includes Serial and EXT (External Signal Interface) connectivity, allowing integration with warehouse management systems and external devices. These connection options make it straightforward to integrate into existing retail operations and logistics workflows. Contact us today to discuss connectivity requirements for your specific environment.

The HP CF313A is a standard-yield cartridge offering 31,500 pages. HP also manufactures high-yield alternatives that provide greater page yields for higher-volume printing environments. For information on which cartridge best fits your printing needs, visit barcodesinc.com or contact our team.

Absolutely—the SATO WWTG40131 is purpose-built for retail tag and label printing with its heavy-duty print mechanism, industrial chassis, and 10 inches-per-second print speed. The durable construction and high-performance processing handle demanding print jobs with ease, making it ideal for busy warehouse and retail operations. We offer this model specifically for environments requiring reliability and consistent output.

The HP CF313A (826A) is designed for HP Color LaserJet printers and multifunction devices that support this cartridge model. Compatibility varies by specific printer model, so we recommend verifying your device's cartridge specifications before ordering. Contact us today to confirm compatibility with your equipment.

The SATO WWTG40131 accommodates media with a 3-inch core and up to 10-inch outer diameter, supporting various label and tag sizes common in retail operations. The 3.1-inch maximum print width provides flexibility for different label formats while maintaining the durability standards SATO is known for. Visit barcodesinc.com for detailed media compatibility information or contact us today for specific application requirements.

The HP CF313A toner cartridge is compatible with HP Color LaserJet multifunction printers that offer print, copy, and scan capabilities. The cartridge will support all these functions on compatible devices. Visit barcodesinc.com to find the right supplies for your specific HP printer model.

The SATO WWTG40131 Barcode Label Printer is also known as SAT-WWTG40131
