SATO WS4-2 – Barcode Label Printer
Full specifications (PDF)
SATO WS4 Barcode Label Printer Model Overview
The XTO WS408/WS412 Thermal Printer is an advanced compact label printer designed for seamless operation in various applications including logistics, retail, and healthcare. With a printing resolution of 203/305 dpi and a remarkable print speed of up to 6 ips, this printer offers exceptional performance for labels, receipts, tags, and wristbands. The wireless operation via Bluetooth™ or Wi-Fi™ enhances connectivity, making it an ideal choice for dynamic environments. Additionally, its compatibility with multiple media types ensures versatility and user-friendliness.
- User-Friendly Operation and Serviceability
- Prints Labels, Receipts, Tags, and Wristbands
- High Printing Resolution of 203 / 305 dpi
- Long 300m Ribbon - Face-in/out
- Available in Thermal Transfer and Direct Thermal Models
- Wireless Operation via Bluetooth™ or Wi-Fi™
- Standard Ethernet connectivity
- Printing Method: Direct Thermal (DT) and Thermal Transfer (TT)
- Print Resolution: 203 dpi (8 dots/mm) / 305 dpi (12 dots/mm)
- Print Speed: Up to 6 ips (152.4mm/s)
- Printer Memory: Flash ROM: 16MB, RAM: 32MB
- Dimensions:
- TT Model: W: 8.68" D: 10.96" H: 7.41"
- DT Model: W: 7.23" D: 8.76" H: 6.53"
- Weight: DT Model: 3.88 lbs. / TT Model: 5.29 lbs.
- Communication Interfaces: USB, LAN, RS232C, Wireless (Optional)
- Operating Temperature: 41 to 104°F (5 to 40°C)
- Certifications: FCC, UL, CSA, CCC, CE, ROHS compliant, Energy Star
Recommended Accessories
Category
- Printer Accessories (11)
- Spare Parts (1)
Recommended Accessories for Model: SATO WT212-400CW-EX1-2 Barcode Label Printer
Top Printer Accessories Purchased With SATO WT212-400CW-EX1-2
-
$222.75 -
$78.75 -
SATO 59-WT202-001 AccessoryDispenser for WS4 Thermal TransferItem on backorder — chat for lead time$97.08
Top Spare Parts Purchased With SATO WT212-400CW-EX1-2
-
SATO 59-WT207-001 Spare PartsSpare Parts, SATO, Lever Ribbon Block, for WS4 Thermal TransferItem on backorder — chat for lead time$21.49
Frequently Asked Questions
What print speeds and resolutions does the SATO WT212-400CW-EX1-2 support?
The SATO WT212-400CW-EX1-2 delivers print speeds of up to 6 inches per second with printing resolutions available at either 203 dpi or 300 dpi. This combination of speed and resolution makes it ideal for high-volume warehouse and healthcare labeling applications where both throughput and print quality are critical.
Is the SATO WT212-400CW-EX1-2 compatible with Cerner healthcare systems?
Yes, the SATO WS4 series, including this model, is fully Cerner-validated for native integration within Cerner health IT systems. This validation ensures patient safety, quality, and efficacy, making it suitable for deployment throughout healthcare supply chains including clinical labs, pharmacies, and hospitals.
What connectivity options are available on this SATO barcode printer?
The SATO WT212-400CW-EX1-2 includes standard Ethernet, USB, and RS232 interfaces, with optional Bluetooth and 802.11 WLAN wireless connectivity. It also supports IPv4/IPv6 protocols, providing flexible integration into modern warehouse and healthcare network environments.
How long is the ribbon capacity on the SATO WT212-400CW-EX1-2?
This model features an impressive 300-meter (984.2 feet) ribbon capacity, which significantly minimizes ribbon changes during operation. The printer also supports versatile ribbon core sizes of 0.5" or 1.0" ID, and can accommodate both wound-in and wound-out configurations for maximum flexibility.
What are the main use cases for the SATO WT212-400CW-EX1-2 printer?
The SATO WT212-400CW-EX1-2 is designed for diverse applications including patient wristband printing, specimen and pathology labels, warehouse picking and pallet management, asset tracking, shipping labels, and pharmacy labeling. Its Cerner validation makes it particularly valuable in healthcare settings, while its compact footprint and high throughput suit warehouse and logistics operations.
How easy is maintenance and serviceability on this SATO printer?
The SATO WT212-400CW-EX1-2 features straightforward replacement of the print head and platen roller, allowing quick return to full operation during routine maintenance. Its user-friendly design includes a 3-color status LED for easy monitoring, and firmware updates can be downloaded directly via USB for convenient management.
