Samsung SNB-5000 Surveillance Camera

Samsung SNB-5000 Security Camera Model Overview

The SNB-5000 is a high performance ONVIF compliant 1.3 Megapixel box camera that incorporates Samsung's WiseNet DSP chipset. Capable of displaying multiple resolutions from CIF (320 x 240) through 16:9 format 720p HD and up to full 1.3 megapixel (1280x1024), the SNB-5000 provides up to 10 video streams and video analytics. This camera features a minimum illumination specification of 0.3 Lux color, True Day / Night operation with ICR, Hybrid (analog) video output, a local SD memory card slot, and is powered via either PoE or 24 VAC. Maximum frame rate is 22 fps @ 1280 x 1024; 30fps @ 720P.

Samsung SNB-5000 Security Camera Overview

The SNB-5000 is a high performance ONVIF compliant 1.3 Megapixel box camera that incorporates Samsung's WiseNet DSP chipset. Capable of displaying multiple resolutions from CIF (320 x 240) through 16:9 format 720p HD and up to full 1.3 megapixel (1280x1024), the SNB-5000 provides up to 10 video streams and video analytics. This camera features a minimum illumination specification of 0.3 Lux color, True Day / Night operation with ICR, Hybrid (analog) video output, a local SD memory card slot, and is powered via either PoE or 24 VAC. Maximum frame rate is 22 fps 1280 x 1024; 30fps 720P.

Detailed Specs

Full specifications (PDF)

Display & Graphics

Image Sensor Type:

CMOS

White Balance Modes:

Auto
Preset
Manual

Maximum Illumination:

0.3 lux

Color Supported:

Color
Monochrome

Swivel:

340°

Video

Video Formats:

MPEG-4
MJPEG

Maximum Video Resolution:

1280 x 1024


Image Formats:

JPEG
BMP

Lens

Lens Mount Type:

CS-Mount

Exposure

Shortest Shutter Speed:

1/30000 Second

Longest Shutter Speed:

1/30 Second

Network & Communication

Connectivity Technology:

Wired

Ethernet:

Yes

Ethernet Technology:

Fast Ethernet

Protocols:

TCP/IP
RTP
UDP
RTSP
NTP
HTTP
HTTPS
SSL
DHCP
FTP
SMTP
ICMP
IGMP
SNMP
ARP
DNS
DDNS

Storage

Flash Memory Capacity:

128 MB

Power Description

Maximum Power Consumption:

8 W

Physical Characteristics

Color:

Dark Gray

Height:

2.4"

Width:

2.8"

Depth:

5.5"

Weight (Approximate):

10.58 oz

Miscellaneous

Package Contents:

iPOLiS SNB-5000 Network Camera
User Manual/IP Installer DVD
User Manual
Power Adapter
C Mount Adapter Auto Iris Lens Connector
Camera Holder (Mount)
2 x Camera Holder (Mount) Screws

System Requirements:

CPU: Pentium 4 / 2.4GHz or higher
Resolution: 1280X1024 pixels or higher
RAM: 1GB or higher
Video Memory: 128MB or higher
Operating Systems: Windows XP, Windows Vista, Windows 7, Linux, Mac OS
Browser: Internet Explorer 6.0 or Higher, Firefox, Google Chrome, Safari

Certifications & Standards:

CE
FCC
UL Listed
ONVIF

Security Features:

HTTPS (SSL) Login Authentication
Digest Login Authentication
IP Address Filtering
User Access Log

Platform Supported:

PC
Mac

Environmentally Friendly:

Yes

Environmental Certification:

RoHS
WEEE

Warranty

Limited Warranty:

3 Year

Item Numbers

GTIN: 0778890688218

UPC: 778890688218

EAN: 0778890688218

UNSPSC: 46171610
