Samsung LH65MGQLBF/ZA Digital Signage Display

The Samsung LH65MGQLBF/ZA Digital Signage Display has been discontinued.
No direct replacement is available.
Please contact us for a suitable substitute.
Samsung - Samsung 650FP-2 65" Full HD LCD Monitor - 16:9 - 65" Class - 1920 x 1080 - 500 Nit - 8 ms - DVI - HDMI - VGA
  • Allows pixels to adjust and accommodate moving scenes and video games with 8 ms response time
  • 16:9 widescreen resolution perfect for watching movies, playing video games and getting on with office work
  • 5,000:1 contrast ratio provides great execution for displaying the darkest black and brightest white
  • View your content easily in well lit areas with 500 Nit brightness
  • HDMI (High Definition Multimedia Interface) offers fantastic sound/video quality and single-cable comfort
  • VESA mount compatibility allows you to mount the display on a wall or with a stand depending on your specific needs
Read More
Discontinued Need Assistance?
Recommended TrueSupport Coverage (/mo.)

x

Are you sure you don't need TrueSupport?

The average internal IT
cost for device support is over per year!

With TrueSupport you're
covered - and for way less!
  • Hardware Helpdesk Support
  • RMA Repair Facilitation
  • OEM Service Contract Management
  • Premium Phone & Email Support
  • Billed annually per device

Only /month
Subtotal ( items)

x
You've just added this product to the cart:

Go To Cart
Add to Quote
Samsung Parts Accessory Model Overview
Products and parts from Samsung.
Samsung LH65MGQLBF/ZA Digital Signage Display Overview

Matrix Video Wall
Built-In Image Enlarging Processor supports various video wall formats. If user wants to install Video Wall as these formats, user doesn't need any other Video Controller Device. Also if viewer uses video & PC Interface, additional Input Signal Distributor is not necessary.

Stay in the loop with DVI-out.
Enjoy superior picture quality with a DVI-out interface that lets you share content between multiple LFDs thanks to an easier-to-connect video matrix. LFDs used to have to be connected to the PC individually, but digital loop out allows you to connect them without connecting to a PC. Better yet, the digital loop out produces a single image without any loss of quality, and there's no need for a separate video signal distributor. It's easy to install and the most cost-effective way to connect multiple displays.

Technical Information
Number of Screens:
1
Screen Size Class:
65"
Viewable Screen Size:
65"
Screen Mode:
Full HD
Response Time:
8 ms
Aspect Ratio:
16:9
Horizontal Viewing Angle:
178°
Vertical Viewing Angle:
178°
Display Orientation:
Landscape
Mount Type:
Wall Mountable
Features:
  • Lamp Error Detection
  • Anti-retention
  • Brightness Sensor
  • Temperature Sensor
  • Picture in Picture
  • Video Wall
  • Button Lock
Video
Maximum Resolution:
1920 x 1080
Contrast Ratio:
5,000:1
Brightness:
500 Nit
Audio
Number of Speakers:
2
Speakers:
Yes
Interfaces/Ports
Network (RJ-45):
Yes
DVI:
Yes
HDMI:
Yes
VGA:
Yes
Component Video:
Yes
Composite Video:
Yes
Built-in Devices
Built-in Devices:
Speaker
Power Description
Input Voltage:
  • 110 V AC
  • 220 V AC
Operating Power Consumption:
470 W
Standby Power Consumption:
2 W
Off-Mode Power Consumption:
1 W
Physical Characteristics
VESA Mount Compatible:
Yes
VESA Mount Standard:
800 x 400
Height:
36.4"
Width:
61.2"
Depth:
4.9"
Weight (Approximate):
127.87 lb
Miscellaneous
Package Contents:
  • 650FP-2 Widescreen LCD Monitor
  • Quick Setup Guide
  • D-Sub Cable
  • Power Cord
  • Warranty Card
  • Application CD
  • Remote Controller
  • Batteries
Certifications & Standards:

EMC:

  • FCC: Part 15, Subpart B class B
  • CE: EN55022, EN55024
  • VCCI: V-3 (CISPR22)
  • KCC: KN22, KN24BSMI
  • CNS13438 (CISPR22)
  • C-Tick
  • AS / NZS3548 (CISPR22)
  • CCC: GB9254-2008, GB17625.1-2003

Safety:

  • UL: UL 60950-1
  • CSA: CSA C22.2 No.60950-1
  • TUV: EN60950-1
  • NEMKO: EN60950-1
  • KC: K60950-1
  • CCC: GB 4943-2001
  • PSB: IEC60950-1
  • GOST: IEC60950-1, EN55022SIQ
  • IEC60950-1, EN55022
  • PCBC: IEC60590-1, EN55022
  • NOM: NOM-019-SCFI-1993
  • IRAM: IEC60950-1
  • SASO: IEC60950-1
Environmentally Friendly:
Yes
Environmental Certification:
RoHS
Warranty
Limited Warranty:
3 Year
Item Numbers
UNSPSC: 43211902
