Features:
- Plug and Play
- Video Wall
Samsung LH55UEPLGC/ZA Digital Signage Display
Part Number:
LH55UEPLGC/ZA
Model:
Parts
Samsung Accessory Model Overview
Products and parts from Samsung.
Samsung LH55UEPLGC/ZA Digital Signage Display Overview
The Samsung UE55A LED LFD contiues to bring new experiences to your professional Video Wall displays. The sleek design allows this product to be slimmer than before, with narrower bezels to catch the eyes of your customers and minimize the loss of images in between each of the assembled LFDs. Such design has brought these to be light weigted, allowing easy installation and efficient space management. Reduced heat lowers the energy consumption and also provides more space for your employees to work without being exposed to great amount of heat. Enhanced readiblity provides better picture quality and our Internal Player is capable of running various contents without the need of any additional equipment.
Technical Information
Processor & Chipset
Processor Speed:
800 MHz
L2 Cache:
512 KB
Memory
Standard Memory:
1 GB
Memory Technology:
DDR3 SDRAM
Display & Graphics
Screen Size:
55"
Display Screen Type:
LCD
Display Resolution:
1920 x 1080
Response Time:
4 ms
Aspect Ratio:
16:9
Horizontal Viewing Angle:
178°
Vertical Viewing Angle:
178°
Backlight Technology:
Edge LED
Audio
Number of Speakers:
2
Speakers:
Yes
RMS Output Power:
20 W
Video
Scan Format:
1080p
Standard Refresh Rate:
60 Hz
Frame Refresh Rate:
240 Hz
Native Contrast Ratio:
5,000:1
Brightness:
380 Nit
Network & Communication
Ethernet:
Yes
Ethernet Technology:
Ethernet
Interfaces/Ports
DVI:
Yes
VGA:
Yes
HDMI:
Yes
Component Video:
Yes
DisplayPort:
Yes
Network (RJ-45):
Yes
Audio Line In:
Yes
Audio Line Out:
Yes
Serial:
Yes
Power Description
Input Voltage:
- 110 V AC
- 220 V AC
Physical Characteristics
VESA Mount Compatible:
Yes
VESA Mount Standard:
400 x 400
Height:
27.3"
Width:
48.1"
Depth:
1.2"
Weight (Approximate):
35.27 lb
Miscellaneous
Package Contents:
- UE55A Digital Signage Display
- Quick Set-up Guide
- Warranty Card
- Application CD
- D-Sub Cable
- Power Cord
- Remote Controller
- Batteries
Additional Information:
- Display Colors: 1.07 Billion
Power Consumption:
- On Mode: 180 W (Max) / 160 W (Typ)
- Off Mode: Less than 1 W
Certifications & Standards:
EMC:
- FCC: Part 15, Subpart B class B
- CE: EN55022, EN55024
- VCCI: V-3 (CISPR22)
- KCC: KN22, KN24BSMI
- CNS13438 (CISPR22)
- C-Tick: AS / NZS3548 (CISPR22)
- CCC: GB9254-2008, GB17625.1-2003
Safety:
- CUL: UL 60950-1
- CSA: CSA C22.2 No.60950-1
- TUV: EN60950-1
- NEMKO: EN60950-1
- KC: K60950-1
- CCC: GB 4943-2001
- PSB: IEC60950-1
- GOST: IEC60950-1, EN55022SIQ
- IEC60950-1, EN55022
- PCBC: IEC60590-1, EN55022
- NOM: NOM-019-SCFI-1993
- IRAM: IEC60950-1
- SASO: IEC60950-1
Energy Star:
Yes
Environmentally Friendly:
Yes
Environmental Certification:
- ENERGY STAR 5.0
- RoHS
Warranty
Limited Warranty:
3 Year
Item Numbers
UNSPSC:
43211902
