Samsung LH55MECPLGA/ZA Digital Signage Display

The Samsung LH55MECPLGA/ZA Digital Signage Display has been discontinued.
No direct replacement is available.
Please contact us for a suitable substitute.
Samsung - Samsung ME-C Series 55" Edge-Lit LED Display - 55" LCD 1 GHz - 1 GB DDR3 SDRAM - 1920 x 1080 - Edge LED - 450 Nit - HDMI - USB - DVI - SerialEthernet
  • Digital Signage Display delivers a highly realistic sound and immersive visual experience thanks to the high pixel density that shows even the most subtle details
  • 55" Signage Display - Designed for unwavering quality and dazzling picture clarity
  • Experience luminescent visual images with LCD display
  • Offers exceptionally smooth and crisp viewing experience due to its 1920 x 1080 full HD resolution
  • Enjoy remarkable picture quality at a low cost with Edge LED technology
  • Features 1920 x 1080 resolution and 1080p scan format for producing sharp and bright images
Read More

Need a different version? See all Samsung Parts Accessories

Discontinued Need Assistance?
Add to Quote
Add to My Shopping List Add to Compare
Samsung LH55MECPLGA/ZA Digital Signage Display
Samsung LH55MECPLGA/ZA Digital Signage Display
Samsung LH55MECPLGA/ZA Digital Signage Display
Samsung Parts Accessory Model Overview
Products and parts from Samsung.
Samsung LH55MECPLGA/ZA Digital Signage Display Overview
Samsung's ME-C Series edge-lit, ultra-slim HD LED commercial displays provide exceptional looking content for businesses. The slim bezel design and 1920 x 1080p full HD resolution with high brightness and contrast on the 55" screen deliver maximum impact messaging. An optional touch overlay offers an interactive experience. And compliance with SMART Signage Platform lowers total cost of ownership.
Technical Information
Features:
  • Ultra Slim
  • Media Player
  • Lamp Error Detection
  • Temperature Sensor
  • Plug and Play
  • Picture in Picture
  • Picture by Picture (PbP)
  • Video Wall
  • Button Lock
  • Smart Scheduling
  • TV Tuner
Processor & Chipset
Processor Speed:
1 GHz
L2 Cache:
512 KB
Processor Core:
Dual-core (2 Core)
Memory
Standard Memory:
1 GB
Memory Technology:
DDR3 SDRAM
Display & Graphics
Screen Size:
55"
Display Screen Type:
LCD
Display Resolution:
1920 x 1080
Response Time:
8 ms
Aspect Ratio:
16:9
Horizontal Viewing Angle:
178°
Vertical Viewing Angle:
178°
Backlight Technology:
Edge LED
HDCP Supported:
Yes
Image Formats:
  • JPEG
  • PNG
Audio
Audio Formats:
AC3
Number of Speakers:
2
Speakers:
Yes
RMS Output Power:
20 W
Sound System:
DTS
Video
Video Formats:
  • MPEG-1
  • MPEG-2
  • H.264/MPEG-4 AVC
  • VC-1
  • MPEG
Scan Format:
1080p
Standard Refresh Rate:
120 Hz
Dynamic Contrast Ratio:
5,000:1
Brightness:
450 Nit
Network & Communication
Ethernet:
Yes
Ethernet Technology:
Ethernet
Interfaces/Ports
USB:
Yes
USB Standard:
USB 2.0
DVI:
Yes
VGA:
Yes
HDMI:
Yes
Component Video:
Yes
DisplayPort:
Yes
Network (RJ-45):
Yes
Audio Line In:
Yes
Audio Line Out:
Yes
Serial:
Yes
Software
Operating System:
Linux
Power Description
Input Voltage:
  • 120 V AC
  • 230 V AC
Power Consumption:
143 W
Physical Characteristics
VESA Mount Compatible:
Yes
VESA Mount Standard:
400 x 400
Height:
28.4"
Width:
49.1"
Depth:
1.2"
Weight (Approximate):
36.16 lb
Miscellaneous
Package Contents:
  • ME-C Series 55" Edge-Lit LED Display
  • Quick Setup Guide
  • Warranty Card
  • Application CD-ROM
  • D-Sub Cable
  • Power Cable
  • Remote Control
  • Batteries
Certifications & Standards:
EMC:
  • FCC (USA.): FCC Part 15, Subpart B, Class A
  • CE (Europe): EN55022, EN55024
  • VCCI (Japan): V-3 (CISPR22)
  • KCC (Korea): KN22, KN24
  • BSMI (Taiwan): CNS13438 (CISPR22)
  • C-Tick (Australia): AS/NZS3548 (CISPR22)
  • CCC (China): GB 9254-2008, GB 17625.1-2003
Security:
  • cUL (USA and Canada.): UL60065
  • TUV (Germany): EN60065
  • CB (Europe): IEC60065 / EN60065
  • EK (Korea): K60065
  • CCC (China): GB8898
  • PSB (Singapore): IEC60065
  • GOST (Russia): IEC60065, EN55022
  • SIQ (Slovenia): IEC60065, EN55022
  • PCBC (Poland): IEC60065, EN55022
  • NOM (Mexico): NOM-001-SCFI-1993
  • IRAM (Argentina) IRAM
  • SASO (Saudi Arabia ): IEC60065
Energy Star:
Yes
Environmentally Friendly:
Yes
Environmental Certification:
  • ENERGY STAR 6.0
  • RoHS
Warranty
Limited Warranty:
3 Year
Item Numbers
UNSPSC: 43211902
